Illinois State Police (ISP) (IL)


Contents

Illinois State Police

Special Operations Command (SOCOM)

  • FCC Application 0005082075 for 436.0-442.0 .323 wt 100KC3F emission for statewide - ISP HQ

Statewide

Starcom21 Conventional Channels

Frequency  Input
License  Type  Tone  Alpha Tag  Description  Mode  Tag
764.64375  794.65375   WPTZ798   RM  156 NAC  ISP 7TAC62 Zone 11/12 - F9 7TAC62 (F2 7TAC62D)  P25  Law Tac
765.14375  795.14375   WPTZ798   RM  156 NAC  ISP 7TAC66 Zone 11/12 - F10 7TAC66 (F3 7TAC66D)  P25  Law Tac
765.39375  795.39375   WPTZ798   RM  156 NAC  ISP 7LAW68 Zone 11/12 - F11 7LAW68 (F4 7LAW68D)  P25  Law Tac
765.49375  795.49375   WPTZ798   RM  156 NAC  ISP 7LAW69 Zone 11/12 - F12 7LAW69 (F5 7LAW69D)  P25  Law Tac
765.64375  795.64375   WPTZ798   RM  156 NAC  ISP 7TAC70 Zone 11/12 - F13 7TAC70 (F6 7TAC70D)  P25  Law Tac
765.89375  795.89375   WPTZ798   RM  156 NAC  ISP 7MOB72 Zone 11/12 - F14 7MOB72 (F7 7MOB72D)  P25  Law Tac
774.10625  804.10625   WPTZ798   RM  156 NAC  ISP 7TAC74 Zone 13M - F8 7TAC74 (F1 7TAC74D)  P25  Law Tac
774.60625  804.60625   WPTZ798   RM  156 NAC  ISP 7TAC78 Zone 13M - F9 7TAC78 (F2 7TAC78D)  P25  Law Tac
775.10625  805.10625   WPTZ798   RM  156 NAC  ISP 7TAC82 Zone 13M - F10 7TAC82 (F3 7TAC82D)  P25  Law Tac
775.00625  805.00625   WPTZ798   RM  156 NAC  ISP 7LAW84 Zone 13M - F11 7LAW84 (F4 7LAW84D)  P25  Law Tac
775.30625  805.30625   WPTZ798   RM  156 NAC  ISP 7LAW85 Zone 13M - F12 7LAW85 (F5 7LAW85D)  P25  Law Tac
775.60625  805.60625   WPTZ798   RM  156 NAC  ISP 7TAC86 Zone 13M - F13 7TAC86 (F6 7TAC86D)  P25  Law Tac
775.50625  805.50625   WPTZ798   RM  156 NAC  ISP 7MOB88 Zone 13M - F14 7MOB88 (F7 7MOB88D)  P25  Law Tac
764.24375  794.24375   WPTZ798   RM  156 NAC  ISP 7CAL59 Zone 13N - F9 7CAL59 (F1 7CAL59D)  P25  Law Tac
764.73750  794.73750   WPTZ798   RM  156 NAC  ISP 7TAC64 Zone 13N - F10 7TAC64 (F2 7TAC63D)  P25  Law Tac
765.99375  795.99375   WPTZ798   RM  156 NAC  ISP 7TAC73 Zone 13N - F12 7TAC73 (F4 7TAC73D)  P25  Law Tac
774.25625  804.25625   WPTZ798   RM  156 NAC  ISP 7CAL75 Zone 13N - F13 7CAL75 (F5 7CAL75D)  P25  Law Tac
774.75625  804.75625   WPTZ798   RM  156 NAC  ISP 7TAC79 Zone 13N - F14 7TAC79 (F6 7TAC79D)  P25  Law Tac
775.25625  805.25625   WPTZ798   RM  156 NAC  ISP 7TAC83 Zone 13N - F15 7TAC83 (F7 7TAC83D)  P25  Law Tac
775.85625  805.85625   WPTZ798   RM  156 NAC  ISP 7TAC89 Zone 13N - F16 7TAC89 (F8 7TAC89D)  P25  Law Tac
764.16875      WPTZ798   67.0 PL  ISP CONVDIR1 Zone 8 - F11   FMN  Law Tac
764.19375      WPTZ798   67.0 PL  ISP CONVDIR2 Zone 8 - F12   FMN  Law Tac
764.21875      WPTZ798   67.0 PL  ISP CONVDIR3 Zone 8 - F13   FMN  Law Tac
764.14375  794.14375   WPTZ798   RM  156 NAC  ISP 7TAC58 Zone 11/12 - F8 (F1 7TAC58D)  P25  Law Tac
765.89375  795.89375   WPTZ798   RM  156 NAC  ISP 7MOB72 Zone 11/12 - F14 7MOB72 (F7 7MOB72D)  P25  Law Tac


'Old ISP VHF Frequencies'

  • Some of these may still be in use locally as needed, for backup or other operations
Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
155.46000  KA5825   BM  CSQ  ISP S/W HF-4 HF4 - Channel 7 (Southern IL)  FMN  Law Talk
155.34000    225.7 PL  MERCI1 225.7 Ambulance-to-ISP District for Communicate (District receives this
freq) [ISP HF-6]
FMN  EMS-Tac
121.27500  KA5825   CSQ  ISP Air 1275 ISP Aircraft ("Henry" units)  AM  Law Tac
122.97500  KA5825   CSQ  ISP Air 2975 ISP Aircraft ("Henry" units)  AM  Law Tac
155.47500  KA5825   67.0 PL  ISPERN 67.0 Nationwide Law Enforcement Emergency [HF-1] (Simulcast)  FMN  Law Talk
155.05500  KA5825   BM  CSQ  I-REACH CSQ Illinois Radio Emergency Assistance Channel [HF-3]  FMN  Interop
155.46000    CSQ  ISP S/W HF-4 ISP District-to-Ambulance transmitting on 155.34 225.7 PL
(receiving this freq)
FMN  Law Dispatch
155.47500  KA5825   CSQ  ISPERN CSQ Nationwide Law Enforcement Emergency [HF-1]   FMN  Law Talk
155.05500  KA5825   156 DPL  I-REACH D156 Illinois Radio Emergency Assistance Channel (Narrowband)  FMN  Interop
155.47500  KN3600   156 DPL  ISPERN D156 Illinois State Police Emergency Radio Network (HF-1) (Narrowband)  FMN  Law Talk


Air Operations

Information

Coverage Map (PDF)

  • Paul 1 - Abraham Lincoln Capital Airport
  • Paul 4 - Whiteside County Airport (D 1,7,8,16,17)
  • Paul 5 - Scott/MidAmerica Airport (D 11,12,13,19,22)
  • Paul 6 - Abraham Lincoln Capital Airport (D 6,9,10,14,18,20)
  • Paul 7 - DuPage Airport (D 2,Chicago,5,15,21)
  • Paul 8 - DuPage Airport (D 2,Chicago,5,15,21)


Support Centers

  • Northern Investigative Support Center
  • Elgin Criminal Intelligence Bureau|
  • Field Support Unit
  • Springfield Gateway Information Sharing Center

Collinsville Crime Scene Services Command

Has 61 employees assigned to offices around the state. They perform such tasks as crime scene processing, photograph imaging, two- and three-dimensional diagrams and animations of crash and crime scenes.

District 1 - Sterling

IL-ISP-d01map.gif HQ located at 3107 E. Lincolnway - IL-2 on east side of town.

Patrols: 1 Whiteside County, 2 Lee County, 3 Carroll County, 4 Ogle County, 5 Dixon, Sterling, Rock Falls overlap patrol with emphasis on Ill Rt. 2 and US Rt. 30 (Lee and Whiteside Counties), 8 Route 88 in Whiteside County, 9 Interstate 39

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
9000  2328  D01 Disp A  ISP District 1: Dispatch A
9001  2329  D01 Disp B  ISP District 1: Dispatch B
9023  233f  D01 Detail A  ISP District 1: Detail A
9024  2340  D01 Detail B  ISP District 1: Detail B
9041  2351  D01 I-REACH  ISP District 1: I-REACH Patch
9049  2359  D01 ISPERN  ISP District 1: ISPERN Patch
9057  2361  D01 LocPatch  ISP District 1: Local Patch
9065  2369  D01 Car2Car  ISP District 1: Car-to-Car
9073  2371  D01 DCI Ops  ISP District 1: Department of Criminal Investigations
9101  238d  D1 Intercom  ISP District 1: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.68000  KSA774   67.0 PL  ISP D1 HF2B Dispatch: Base-to-Mobiles (Old)  FMN  Law Dispatch
154.68000  KA5825   110.9 PL  ISP D1 HF2M Dispatch: Mobiles-to-Base (Old)  FMN  Law Dispatch
764.16875  WPTZ798   155 DPL  ISP D1 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.16875  WPTZ798   412 DPL  ISP D1 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch


District 2 - Elgin

IL-ISP D2map.gif Serves counties of: McHenry, Lake, DeKalb, Kane, DuPage Located at 777 S. State - on IL-31 across from Elgin State Hospital

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
9002  232a  D02 Disp A  ISP District 2: Dispatch A
9003  232b  D02 Disp B  ISP District 2: Dispatch B
9004  232c  D02 Disp C  ISP District 2: Dispatch C
9025  2341  D02 Detail A  ISP District 2: Detail A
9026  2342  D02 Detail B  ISP District 2: Detail B
9042  2352  D02 IREACH  ISP District 2: I-REACH Patch
9050  235a  D02 ISPERN  ISP District 2: ISPERN Patch
9058  2362  D02 LocPatch  ISP District 2: Local Patch
9066  236a  D02 Car2Car  ISP District 2: Car-to-Car
9074  2372  D02 DCI Ops  ISP District 2: Department of Criminal Investigations
9102  238e  D2 Intercom  ISP District 2: District 2 Intercom
9141  23b5  D02 Detail C  ISP District 2: Detail C

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.69500  KSB233   67.0 PL  ISP D2 HF-2B Dispatch: Base-to-Mobiles / Scales  FMN  Law Dispatch
154.69500  KA5825   110.9 PL  ISP D2 HF-2M Dispatch: Mobiles-to-Base / Scales  FMN  Law Dispatch
764.19375  WPTZ798   156 DPL  ISP D2 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.19375  WPTZ798   412 DPL  ISP D2 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch


District Chicago

IL-ISP dchimap.gif IL-ISP Dchi-2.gif

DEC HEX Mode Alpha Tag Description
9005  232d  DChi Metro A  ISP District Chicago: Ch A - Priority (Emerg Broadcasts/Admin)
9006  232e  DChi Metro B  ISP District Chicago: Ch B - North Sector (Expressway Patrol)
9007  232f  DChi Metro C  ISP District Chicago: Ch C - South Sector (Expressway Patrol)
9008  2330  DChi Metro D  ISP District Chicago: Ch D:
9009  2331  DChi Metro E  ISP District Chicago: Ch E - Commercial Veh, MC Units, HazMat
9010  2332  DChi Metro F  ISP District Chicago: Ch F - Secretary of State Police/Natural Resources
9011  2333  DChi Metro G  ISP District Chicago: Ch G - Paul Sam (Protective Services Unit)
9027  2343  DCh Detail A  ISP District Chicago: Detail A
9028  2344  DCh Detail B  ISP District Chicago: Detail B
9029  2345  DCh Detail C  ISP District Chicago: Detail C / Ops at James R. Thompson Center (Chi)
9043  2353  DCh I-REACH  ISP District Chicago: I-REACH Patch
9051  235b  DCh ISPERN  ISP District Chicago: ISPERN Patch
9059  2363  DChi Metro H  ISP District Chicago: Ch H - Chicago Local
9067  236b  DChi Car2Car  ISP District Chicago: Car-to-Car (IDOT D1 ETP Minutemen-Contact)
9075  2373  DChi DCI Ops  ISP District Chicago: Department of Criminal Investigations
9103  238f  DCh Intercom  ISP District Chicago: Intercom
9117  239d  DChi CPD-N  Chicago Police Interagency North
9118  239e  DChi CPD-S  Chicago Police Interagency South

Cook County, 9511 W Harrison - Des Plaines - in Maine North Complex

HF-2 - 154.935 - is in use as an alternate / backup to the GE-EDACS trunked system and for special details. This is the old district 3 HF-2. District 4's old HF- - 154.680, is thought to be totally out of service. HF-4 - 155.460 is used frequently as a contact channel to District 15 (tollways) and as a VHF car to car.

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
9005  232d  DChi Metro A  ISP District Chicago: Ch A - Priority (Emerg Broadcasts/Admin)
9006  232e  DChi Metro B  ISP District Chicago: Ch B - North Sector (Expressway Patrol)
9007  232f  DChi Metro C  ISP District Chicago: Ch C - South Sector (Expressway Patrol)
9008  2330  DChi Metro D  ISP District Chicago: Ch D:
9009  2331  DChi Metro E  ISP District Chicago: Ch E - Commercial Veh, MC Units, HazMat
9010  2332  DChi Metro F  ISP District Chicago: Ch F - Secretary of State Police/Natural Resources
9011  2333  DChi Metro G  ISP District Chicago: Ch G - Paul Sam (Protective Services Unit)
9027  2343  DCh Detail A  ISP District Chicago: Detail A
9028  2344  DCh Detail B  ISP District Chicago: Detail B
9029  2345  DCh Detail C  ISP District Chicago: Detail C / Ops at James R. Thompson Center (Chi)
9043  2353  DCh I-REACH  ISP District Chicago: I-REACH Patch
9051  235b  DCh ISPERN  ISP District Chicago: ISPERN Patch
9059  2363  DChi Metro H  ISP District Chicago: Ch H - Chicago Local
9067  236b  DChi Car2Car  ISP District Chicago: Car-to-Car (IDOT D1 ETP Minutemen-Contact)
9075  2373  DChi DCI Ops  ISP District Chicago: Department of Criminal Investigations
9103  238f  DCh Intercom  ISP District Chicago: Intercom
9117  239d  DChi CPD-N  Chicago Police Interagency North
9118  239e  DChi CPD-S  Chicago Police Interagency South

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
155.46000  KSB231   BM  CSQ  ISP S/W HF-4 Car-to-Car / contact with District 15-Tollways  FMN  Law Tac
154.93500  KSB242   BM    ISP DCh HF-2 Special Details/Alternate/Back-up  FMN  Law Tac
794.19375  WPTZ798   412 DPL  ISP DCh MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch
764.19375  WPTZ798   156 DPL  ISP DCh MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch


District 5 - Romeoville

IL-ISP D5map.gif 16658 Broadway - Romeoville/Lockport - next to Statesville Prison

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
9013  2335  D05 Disp A  ISP District 5: Dispatch A
9014  2336  D05 Disp B  ISP District 5: Dispatch B
9030  2346  D05 Detail A  ISP District 5: Detail A
9031  2347  D05 Detail B  ISP District 5: Detail B
9044  2354  D05 I-REACH  ISP District 5: I-REACH Patch
9052  235c  D05 ISPERN  ISP District 5: ISPERN Patch
9060  2364  D05 LocPatch  ISP District 5: Local Patch
9068  236c  D05 Car2Car  ISP District 5: Car-to-Car
9076  2374  D05 DCI Ops  ISP District 5: Department of Criminal Investigations
9104  2390  D5 Intercom  ISP District 5: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.68000  KSA776   BM  CSQ  ISP D6 HF-2 Dispatch (Old)  FMN  Law Dispatch
764.16875  WPTZ798   155 DPL  ISP D6 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.16875  WPTZ798   412 DPL  ISP D6 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch


District 6 - Livingston

IL-ISP D6map.gif Migrated to StarCom21 8/14/2007 - Located US Highway 66 West - South of town on old US-66

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
13000  32c8  D06 Disp A  ISP District 6: Dispatch A
13001  32c9  D06 Disp B  ISP District 6: Dispatch B
13013  32d5  D06 Detail A  ISP District 6: Detail A
13014  32d6  D06 Detail B  ISP District 6: Detail B
13026  32e2  D06 I-REACH  ISP District 6: I-REACH Patch
13032  32e8  D06 ISPERN  ISP District 6: ISPERN Patch
13038  32ee  D06 LocPatch  ISP District 6: Local Patch
13044  32f4  D06 Car2Car  ISP District 6: Car-to-Car
13050  32fa  D06 DCI Ops  ISP District 6: Department of Criminal Investigations
13073  3311  D6 Intercom  ISP District 6: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.84500  KSB229   67.0 PL  ISPD7 HF-2B Dispatch: Base-to-Mobiles (Old)  FMN  Law Dispatch
764.21875  WPTZ798   162 DPL  ISP D7 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.21875  WPTZ798   413 DPL  ISP D7 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch


District 7 - East Moline

IL-ISP D07map.gif HQ Located at 800 Hillcrest Road - "Rock Island" on State Hospital grounds.

Note: the interchange of I-74 and I-80 in Henry County is known as "the Big X".

Patrol Areas below are as assigned in the past. There may be changes in the Galesburg area and the Quad-Cities metro area. Shift announcements generally heard at about 0700, 0800, 1600, 1700 & 2200.

    1. I-80 & I-88 Northern Rock Island County
    2. I-74 & I-280 Central Rock Island County
    3. (3) I-80 Henry County
    4. (4) unknown or not in use
    5. (5) I-74 Henry County
    6. (6) I-80 Knox County
      • (A) North Northern Rock Island County above I74
      • (A) South Southern Rock Island County below I74
      • (B) Mercer County
      • (C) Henry County
      • (D) Knox County

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
9015  2337  D07 Disp A  ISP District 7: Dispatch A - Main
9016  2338  D07 Disp B  ISP District 7: Dispatch B - Admin/Special Detail
9032  2348  D07 Detail A  ISP District 7: Detail A
9033  2349  D07 Detail B  ISP District 7: Detail B
9045  2355  D07 I-REACH  ISP District 7: I-REACH Patch
9053  235d  D07 ISPERN  ISP District 7: ISPERN Patch
9061  2365  D07 LocPatch  ISP District 7: Local Patch
9069  236d  D07 Car2Car  ISP District 7: Car-to-Car
9077  2375  D07 DCI Ops  ISP District 7:Department of Criminal Investigations
9105  2391  D7 Intercom  ISP District 7: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
155.52000  KSB228   205 DPL  ISP D8 HF2B District 8: Alerts / Broadcasts   FMN  Law Dispatch
764.19375  WPTZ798   156 DPL  ISP D8 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.19375  WPTZ798   412 DPL  ISP D8 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch


District 8 - Metamora

IL-ISP D08map.gif

HQ Located at IL-116 East - Metamora

Patrol Zones may be divided as East and West with the river as the dividing point.

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
13002  32ca  D08 Disp A  ISP District 8: Dispatch A
13003  32cb  D08 Disp B  ISP District 8: Dispatch B
13015  32d7  D08 Detail A  ISP District 8: Detail A / Air Operations
13016  32d8  D08 Detail B  ISP District 8: Detail B
13027  32e3  D08 I-REACH  ISP District 8: I-REACH Patch
13033  32e9  D08 ISPERN  ISP District 8: ISPERN Patch
13039  32ef  D08 LocPatch  ISP District 8: Local Patch
13045  32f5  D08 Car2Car  ISP District 8: Car-to-Car
13051  32fb  D08 DCI Ops  ISP District 8: Department of Criminal Investigations
13074  3312  D8 Intercom  ISP District 8: Intercom

Conventional/Old Frequencies (still some use)

Frequency  Input
License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.93500      KNNU245   67.0 PL  ISP D9 HF-2B Dispatch: Base-to-Mobiles (Old)  FMN  Deprecated
155.44500      KSC334   BM  CSQ  ISP ComCntr Command Center - Springfield  FMN  Deprecated
156.00000      KS3183   CSQ  ISP D9 C2C Car-to-Car (Old)  FM  Deprecated
857.73750      WNMF342   82.5 PL  ICJIA Data ICJIA Data   FM  Data
156.00000      KS3183   CSQ  ISP D9 U2U Unit-to-Unit (licensed only to ISP District 9)  FM  Deprecated
460.35000  465.35000   WQIG495   RM  151.4 PL  ISPHQ Maint ISP Headquarters - Building Maintenance (801 S Seventh - Spfld)  FMN  Public Works
460.45000  465.45000   WQIG495   RM  071 DPL  ISPHQ Clean ISP Headquarters - Maintenance / Janitorial (801 S Seventh -
Spfld)
FMN  Public Works
764.21875      WPTZ798   162 DPL  ISP D9 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.21875      WPTZ798   413 DPL  ISP D9 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch
154.93500      KNNU245   BM  223 DPL  ISP D9Alerts District 9: Alerts / Broadcasts  FMN  Law Dispatch


District 9 - Springfield

IL-ISP D09map.gif District Map IL-ispd9v1dot1jcat79.gif Patrol Areas Migrated to StarCom21 8/2/07 -- HQ Located south of Springfield on I-55

Patrol Areas: (Zone 1) Christian County (Zone 2) Sangamon County, East of I-55 (Zone 3) Sangamon County, West of I-55 (Zone 4) Logan County (Zone 5) Mason County (Zone 6) Menard County (Zone 7) Cass County (Zone 8) Morgan County

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
13004  32cc  D09 Disp A  ISP District 9: Dispatch A - Main/Operations
13005  32cd  D09 Disp B  ISP District 9: Dispatch B - On/Off Duty; Details
13006  32ce  D09 Disp C  ISP District 9: Dispatch C
13017  32d9  D09 Detail A  ISP District 9: Detail A
13018  32da  D09 Detail B  ISP District 9: Detail B
13019  32db  D09 Detail C  ISP District 9: Detail C
13028  32e4  D09 I-REACH  ISP District 9: I-REACH Patch
13034  32ea  D09 ISPERN  ISP District 9: ISPERN Patch
13040  32f0  D09 LocPatch  ISP District 9: Local Patch (State Fair Interop w/ City. County)
13046  32f6  D09 Car2Car  ISP District 9: Car-to-Car
13052  32fc  D09 DCI Ops  ISP District 9: Department of Criminal Investigations
13075  3313  D9 Intercom  ISP District 9: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.69500  KSA464   251 DPL  ISP D10 HFB2 Dispatch: Champaign/Urbana area (no 67.0 PL as of 9/10)  FMN  Law Dispatch
764.46875  WPTZ798   165 DPL  ISP D10 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.46875  WPTZ798   423 DPL  ISP D10 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch
39.46000  KSA464   BM  CSQ  S/W LB P2P Point-to-Point (w/ Danville city?)  FM  Law Talk


District 9 - Springfield - Illinois State Fairgrounds

  • UPDATE 8/10/07*

13063 3307 D ISP SpEvnt 2A Illinois State Police: Special Event - Zone 2A / State Fair 2007 13064 3308 D ISP SpEvnt Z2B Illinois State Police: Special Event - Zone 2B / State Fair 2007

State Fair is 2nd or 3rd week of August in Springfield (155.46 is formerly the active dispatch; heard "Fairgrounds" to "Walking xx" xx=units heard A,B,C,D,F,G,H,29, ALL other units go by their regular district number) Also Tac 1, 2, 3, 4 -- "Backstage Unit" Will call "Springfield" if calling ISP District 9 Dispatch.

Fairgrounds dispatch appears to have a city TRS radio in the center as they were heard on Fire-1 talkgroup. America may also have a portable on 155.46 to respond to EMS calls.

District 10 - Pesotum (Champaign)

IL-ISP D10map.gif

Migrated to StarCom21 8/9/07 -- HQ located at US-45 South, at I-57

"X-Ray" Units - Designated as "X" because "10" would sound like 10 codes

East Central Illinois (Drug) Task Force

Made up of at least one officer each from Mattoon, Charleston, EIU Police, Coles County Sheriff, Moultrie County Sheriff, Shelby County Sheriff, Arcola. Serves entire counties of Douglas, Coles, Moultrie, and Shelby. Investigates cases of narcotics and money laundering, as well as assists agencies in investigating other major crimes. Oficers assigned to the force are commissioned as Illinois State Police Investigators and can even work for the DEA. Units on 154.695 are "5-Ida".

District 10 is probably divided up into zones then into patrol areas. Please updated this information here if known.

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
13007  32cf  D10 Disp A  ISP District 10: Dispatch A - Champaign-Urbana
13008  32d0  D10 Disp B  ISP District 10: Dispatch B - Rest of District
13020  32dc  D10 Detail A  ISP District 10: Detail A
13021  32dd  D10 Detail B  ISP District 10: Detail B
13029  32e5  D10 I-REACH  ISP District 10: I-REACH Patch
13035  32eb  D10 ISPERN  ISP District 10: ISPERN Patch
13041  32f1  D10 LocPatch  ISP District 10: Local Patch
13047  32f7  D10 Car2Car  ISP District 10: Car-to-Car
13053  32fd  D10 DCI Ops  ISP District 10: Department of Criminal Investigations
13076  3314  D10 Intercom  ISP District 10: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
155.37000  KSB235   CSQ  ISP S/W P2P Point-to-Point {Link to St Louis / MO State} [was 67.0 TX]  FMN  Law Talk
764.21875  WPTZ798   162 DPL  ISP D11 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.21875  WPTZ798   413 DPL  ISP D11 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch
775.85625  WPTZ798   61F NAC  7TAC89 61F Operations (heard Madison Co)  P25  Law Tac
155.05500  KSB235   67.0 PL  I-REACH 67.0 Illinois Radio Emergency Assistance Channel (Patched to D11
STARCOM21 Talkgroup)
FMN  Interop
154.66500  KSB235   306 DPL  ISP D11Alert District 11: Alerts / Broadcasts  FMN  Law Dispatch


District 11 - Collinsville

IL-ISP D11map.gif HQ Located near I-55/64/70 at I-255 in western Collinsville

Codes

  • Post 1 = D11 HQ in Collinsville
  • MLK = Martin Luther King Bridge off of 55/64/70 @ Mississippi River
  • 4 I's = Intersection of I-55, I-270 and I-70 near Troy/Glen Carbon
  • MEGSI - Drug Investigation Team comprised of officers & deputies from agencies with-in the district

Air Operations Center

Located at Mid-America Airport in Mascoutah. 2 ISP officers use a Cessna 182 equipped with FLIR heat seeking system, which can be used to search for missing persons, surveillence, etc.

    • Officers appear to have access to SC21 D18 C2C (10/07)

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
17000  4268  D11 Disp A  ISP District 11: Dispatch A
17001  4269  D11 Disp B  ISP District 11: Dispatch B
17002  426a  D11 Disp C  ISP District 11: Dispatch C: Investigations (6-Ida, V-, AV)
17016  4278  D11 Detail A  ISP District 11: Detail A
17017  4279  D11 Detail B  ISP District 11: Detail B (ie Liquor Stings)
17018  427a  D11 Detail C  ISP District 11: Detail C: Motorcycle Dispatch / Ida Details
17019  427b  D11 Detail D  ISP District 11: Detail D
17031  4287  D11 I-REACH  ISP District 11: I-REACH Patch
17037  428d  D11 ISPERN  ISP District 11: ISPERN Patch
17043  4293  D11 LocPatch  ISP District 11: Local Patch
17049  4299  D11 Car2Car  ISP District 11: Car-to-Car
17055  429f  D11 DCI Ops  ISP District 11: Department of Criminal Investigations
17078  42b6  D11 Intercom  ISP District 11: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.68000  KSB236   315 DPL  ISP D12 HF2A District 12: Alerts / Broadcasts (in use 6/14)  FMN  Law Dispatch
764.19375  WPTZ798   156 DPL  ISP D12 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.19375  WPTZ798   412 DPL  ISP D12 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch
154.68000  KSB236   412 DPL  ISP D12 HF2B District 12: Alerts / Broadcasts (still in use?)  FMN  Law Dispatch


District 12 - Effingham

IL-ISP D12map.gif Migrated to StarCom21 7/27/07 -- HQ Located at

South Central IL Drug Task Force

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
17003  426b  D12 Disp A  ISP District 12: Dispatch A
17004  426c  D12 Disp B  ISP District 12: Dispatch B
17005  426d  D12 Disp C  ISP District 12: Dispatch C
17020  427c  D12 Detail A  ISP District 12: Detail A
17032  4288  D12 I-REACH  ISP District 12: I-REACH Patch
17038  428e  D12 ISPERN  ISP District 12: ISPERN Patch
17044  4294  D12 LocPatch  ISP District 12: Local Patch
17050  429a  D12 Car2Car  ISP District 12: Car-to-Car
17056  42a0  D12 DCI Ops  ISP District 12: Department of Criminal Investigations
17079  42b7  D12 Intercom  ISP District 12: Intercom

Conventional/Old Frequencies (still some use)

Frequency  Input
License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.90500      KSB234     ISP D13 DCI DCI - Old (still on air 2012)  FMN  Law Dispatch
855.46250  810.46250   WQCP383   BM    ICJIA DataDQ Illinois Criminal Justice Information Authority: Alerts Network   Telm  Data
764.46875      WPTZ798   165 DPL  ISP D13 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.46875      WPTZ798   423 DPL  ISP D13 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch
154.93500      KSB234   371 DPL  ISP D13Alert District 13: Alerts / Broadcasts [HF-2] (was 413 DPL)  FMN  Law Dispatch


District 13 - Du Quoin

IL-ISP D13map.gif HQ Located at across from State Fairground, Called "Du Quoin State"

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
17006  426e  D13 Disp A  ISP District 13: Dispatch A
17007  426f  D13 Disp B  ISP District 13: Dispatch B - Motorcycle Dispatch
17008  4270  D13 Disp C  ISP District 13: Dispatch C
17021  427d  D13 Detail A  ISP District 13: Detail A
17022  427e  D13 Detail B  ISP District 13: Detail B
17023  427f  D13 Detail C  ISP District 13: Detail C
17033  4289  D13 I-REACH  ISP District 13: I-REACH Patch
17039  428f  D13 ISPERN  ISP District 13: ISPERN Patch
17045  4295  D13 LocPatch  ISP District 13: Local Patch
17051  429b  D13 Car2Car  ISP District 13: Car-to-Car
17057  42a1  D13 DCI Ops  ISP District 13: Department of Criminal Investigations
17080  42b8  D13 Intercom  ISP District 13: Intercom [in use, Encrypted 3/13]

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.69500  KSA775     ISP D14 HF2B Alerts / Broadcasts [Need DPL tone]  FMN  Law Dispatch
764.16875  WPTZ798   155 DPL  ISP D14 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.16875  WPTZ798   412 DPL  ISP D14 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch


District 14


STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
13009  32d1  D14 Disp A  ISP District 14: Dispatch A
13010  32d2  D14 Disp B  ISP District 14: Dispatch B
13022  32de  D14 Detail A  ISP District 14: Detail A
13023  32df  D14 Detail B  ISP District 14: Detail B
13030  32e6  D14 I-REACH  ISP District 14: I-REACH Patch
13036  32ec  D14 ISPERN  ISP District 14: ISPERN Patch
13042  32f2  D14 LocPatch  ISP District 14: Local Patch
13048  32f8  D14 Car2Car  ISP District 14: Car-to-Car
13054  32fe  D14 DCI Ops  ISP District 14: Department of Criminal Investigations
13077  3315  D14 Intercom  ISP District 14: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
155.52000  KSF947   BM  110.9 PL  ISP D16 HF2 Dispatch [HF-2] (Old)  FMN  Law Dispatch
764.21875  WPTZ798   162 DPL  ISP D16 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.21875  WPTZ798   413 DPL  ISP D16 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch


District 15


STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
2026  7ea  D15 2026 ENC  ISP District 15: Encrypted
2027  7eb  D15 Detail C  ISP District 15: Detail C
2028  7ec  D15 Ops 2028  ISP District 15: Operations
2029  7ed  D15 c2cNorth  ISP District 15: Car-to-Car - North
2030  7ee  D15 c2cSouth  ISP District 15: Car-to-Car - South
2031  7ef  D15 Detail A  ISP District 15: Detail A
2032  7f0  D15 Detail B  ISP District 15: Detail B
2033  7f1  D15 Detail D  ISP District 15: Detail D
2034  7f2  D15 LocPatch  ISP District 15: Local Patch
2035  7f3  D15 Common  ISP District 15: Common
2036  7f4  D15 ISPERN  ISP District 15: ISPERN Patch
2037  7f5  D15 I-REACH  ISP District 15: I-REACH Patch
2038  7f6  D15 RadioTch  ISP District 15: Radio Technicians
9098  238a  D15 DispN F5  ISP District 15: Tollway North Patrol [Ch 5]
9099  238b  D15 DispS F7  ISP District 15: Tollway South Patrol [Ch 7]
9100  238c  D15 TollwayC  ISP District 15: Tollway Channel (Statewide)
9112  2398  D15 Intercom  ISP District 15: Intercom
9142  23b6  D15 RadioTec  ISP District 15: Tollway Radio Techs

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
764.46875  WPTZ798   165 DPL  ISP D17 MX-O Vehicular Repeater - Out (to SC21)  FMN  Law Dispatch
794.46875  WPTZ798   423 DPL  ISP D17 MX-I Vehicular Repeater - In (to SC21)  FMN  Law Dispatch
155.46000  KEO371   BM  67.0 PL  ISP HF4 67.0 HF-4 (back-up to Starcom)  FMN  Law Dispatch
155.44500  KEO371   BM    ISP D17Alert Alerts / Broadcasts - Future  FMN  Law Dispatch


District 16 - Rockford

ISP-D16map.gif HQ Located at just north of US-52 in Pecotonica in western Winnebago County.

District 15 covers the Northwest Tollway that takes in Interstate 90 which enters southern Boone County before entering eastern Winnebago County and turns north to the Wisconsin State line.

Patrol Areas: (11) Northside of Boone County (12) Southside of Boone County (21) Northeast Winnebago County (22) Southeast Winnebago County (23) Southwest Winnebago County (3) Stephenson County (4) Jo Daviess County

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
9017  2339  D16 Disp A  ISP District 16: Dispatch A
9018  233a  D16 Disp B  ISP District 16: Dispatch B
9034  234a  D16 Detail A  ISP District 16: Detail A
9035  234b  D16 Detail B  ISP District 16: Detail B
9046  2356  D16 I-REACH  ISP District 16: I-REACH Patch
9054  235e  D16 ISPERN  ISP District 16: ISPERN Patch
9062  2366  D16 LocPatch  ISP District 16: Local Patch
9070  236e  D16 Car2Car  ISP District 16: Car To Car
9078  2376  D16 DCI Ops  ISP District 16: Department of Criminal Investigations
9106  2392  D16 Intercom  ISP District 16: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
857.73750    82.5 PL  ICJIA Lfld ICJIA Data   FM  Data
957.55000  WQAX855     ISP D18 MW-2 Microwave Link (Beaver Dam)  Telm  Data
953.95000  WQAX857     ISP D18 MW-1 Microwave Link (ATC Harms (7m N of Carlinville)  Telm  Data
764.16875  WPTZ798   155 DPL  ISP D18 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.16875  WPTZ798   412 DPL  ISP D18 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch
155.44500  WQEP339   BM  412 DPL  ISP D18Alert Alerts / Broadcasts (No longer in use?)  FMN  Law Dispatch
155.44500  WQEP339   BM  516 DPL  ISP D18 HF2 Alerts / Broadcasts [HF-2]  FMN  Law Dispatch


District 17 - LaSalle

IL-ISP-D17map.gif Patrol Areas: (1) Interstate 80 in LaSalle County (2) Interstate 80 and Interstate180 in Bureau County (3) Northern LaSalle County (4) Southern LaSalle County (5) Southern Bureau County (6) Route 88 in Whiteside County (7) Putnam County (8) Interstate 39 north of Interstate 80 in LaSalle County (9) Interstate 39 South of Interstate 80 in LaSalle County

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
9019  233b  D17 Disp A  ISP District 17: Dispatch A
9020  233c  D17 Disp B  ISP District 17: Dispatch B
9036  234c  D17 Detail A  ISP District 17: Detail A
9037  234d  D17 Detail B  ISP District 17: Detail B
9047  2357  D17 I-REACH  ISP District 17: I-REACH Patch
9055  235f  D17 ISPERN  ISP District 17: ISPERN Patch
9063  2367  D17 LocPatch  ISP District 17: Local Patch
9071  236f  D17 Car2Car  ISP District 17: Car-to-Car / Portable Scales
9079  2377  D17 DCI Ops  ISP District 17: Department of Criminal Investigations
9107  2393  D17 Intercom  ISP District 17: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.92000  KSI983   624 DPL  ISP D19 HF-2 District 19: Alerts / Broadcasts (was 412 DPL)  FMN  Law Dispatch
764.16875  WPTZ798   155 DPL  ISP D19 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.16875  WPTZ798   412 DPL  ISP D19 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch


District 18 - Litchfield

Image-IL-ISP-D18map.gif Migrated to StarCom21 7/31/07 -- HQ located on IL-16, just west of I-55 in Litchfield. Patrol Zones: East Patrol - Macoupin, Montgomery West Patrol - Calhoun, Greene, Jersey (may also be county specific zones)

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
17009  4271  D18 Disp A  ISP District 18: Dispatch A
17010  4272  D18 Disp B  ISP District 18: Dispatch B
17024  4280  D18 Detail A  ISP District 18: Detail A
17025  4281  D18 Detail B  ISP District 18: Detail B
17034  428a  D18 I-REACH  ISP District 18: I-REACH Patch
17040  4290  D18 ISPERN  ISP District 18: ISPERN Patch
17046  4296  D18 LocPatch  ISP District 18: Local Patch
17052  429c  D18 Car2Car  ISP District 18: Car-to-Car / Speed Traps
17058  42a2  D18 DCI Ops  ISP District 18: Department of Criminal Investigations
17081  42b9  D18 Intercom  ISP District 18: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
764.19375  WPTZ798   156 DPL  ISP D20 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.19375  WPTZ798   412 DPL  ISP D20 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch
154.68000  KGY335   662 DPL  ISP D20Alert District 20: Alerts / Broadcasts   FMN  Law Dispatch


District 19 - Carmi


STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
17011  4273  D19 Disp A  ISP District 19: Dispatch A
17012  4274  D19 Disp B  ISP District 19: Dispatch B
17013  4275  D19 Disp C  ISP District 19: Dispatch C
17026  4282  D19 Detail A  ISP District 19: Detail A
17027  4283  D19 Detail B  ISP District 19: Detail B
17035  428b  D19 I-REACH  ISP District 19: I-REACH Patch
17041  4291  D19 ISPERN  ISP District 19: ISPERN Patch
17047  4297  D19 LocPatch  ISP District 19: Local Patch
17053  429d  D19 Car2Car  ISP District 19: Car-to-Car
17059  42a3  D19 DCI Ops  ISP District 19: Department of Criminal Investigations
17082  42ba  D19 Intercom  ISP District 19: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
764.19375  WPTZ798   156 DPL  ISP D21 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.19375  WPTZ798   412 DPL  ISP D21 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch


District 20 - Pittsfield


STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
13011  32d3  D20 Disp A  ISP District 20: Dispatch A
13012  32d4  D20 Disp B  ISP District 20: Dispatch B
13024  32e0  D20 Detail A  ISP District 20: Detail A
13025  32e1  D20 Detail B  ISP District 20: Detail B
13031  32e7  D20 I-REACH  ISP District 20: I-REACH Patch
13037  32ed  D20 ISPERN  ISP District 20: ISPERN Patch
13043  32f3  D20 LocPatch  ISP District 20: Local Patch
13049  32f9  D20 Car2Car  ISP District 20: Car-to-Car
13055  32ff  D20 DCI Ops  ISP District 20: Department of Criminal Investigations
13078  3316  D20 Intercom  ISP District 20: Intercom

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.68000  KSG291   BM  754 DPL  ISP D22 HF-2 District 22: Alerts / Broadcasts  FMN  Law Dispatch
764.21875  WPTZ798   162 DPL  ISP D22 MX-O Vehicular Repeater/Mobile Extender - Out (to SC21)  FMN  Law Dispatch
794.21875  WPTZ798   413 DPL  ISP D22 MX-I Vehicular Repeater/Mobile Extender - In (to SC21)  FMN  Law Dispatch


District 21 - Ashkum


STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
9021  233d  D21 Disp A  ISP District 21: Dispatch A
9022  233e  D21 Disp B  ISP District 21: Dispatch B
9038  234e  D21 Detail A  ISP District 21: Detail A
9039  234f  D21 Detail B  ISP District 21: Detail B
9040  2350  D21 Detail C  ISP District 21: Detail C
9048  2358  D21 I-REACH  ISP District 21: I-REACH Patch
9056  2360  D21 ISPERN  ISP District 21: ISPERN Patch
9064  2368  D21 LocPatch  ISP District 21: Local Patch
9072  2370  D21 Car2Car  ISP District 21: Car-to-Car
9080  2378  D21 DCI Ops  ISP District 21: Department of Criminal Investigations
9108  2394  D21 Intercom  ISP District 21: Intercom

Conventional/Old Frequencies (still some use)


District 22 - Ullin

1d22map.gif Patrol Areas: (1) Union County (2) Pulaski County (3) Alexander County (4) Johnson County (5)Massac County (6) Pope County (7) Hardin County

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
17014  4276  D22 Disp A  ISP District 22: Dispatch A
17015  4277  D22 Disp B  ISP District 22: Dispatch B
17028  4284  D22 Detail A  ISP District 22: Detail A
17029  4285  D22 Detail B  ISP District 22: Detail B
17030  4286  D22 Detail C  ISP District 22: Detail C
17036  428c  D22 I-REACH  ISP District 22: I-REACH Patch
17042  4292  D22 ISPERN  ISP District 22: ISPERN Patch
17048  4298  D22 LocPatch  ISP District 22: Local Patch
17054  429e  D22 Car2Car  ISP District 22: Car-to-Car
17060  42a4  D22 DCI Ops  ISP District 22: Department of Criminal Investigations
17083  42bb  D22 Intercom  ISP District 22: Intercom

Conventional/Old Frequencies (still some use)

Frequency  Input
License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.86000  155.97000   WPXU646   RM  141.3 PL  DeK Sheriff Sheriff: Dispatch (Sycamore)  FM  Law Dispatch
153.48500  159.01500   WPJP732   RM  192.8 PL  DeKalb Fire Fire: Countywide Dispatch   FM  Fire Dispatch
155.25000      KSA291   BM  77.0 PL  DeKlb Police {Link to/Back-Up} DeKalb City Police Dispatch (rarely used)  FM  Law Dispatch
154.77000      KSA291   141.3 PL  DeK SD Tac10 Sheriff: Tactical (Tac 10)  FM  Law Tac
159.12000  150.92000   KFF244   RM  146.2 PL  DeK Highway1 Highway Department (Road Maintenance, Plows)  FM  Public Works
159.18000      KFF244   RM    DeK Highway2 Highway Department (may not be used)  FM  Public Works
154.01000      WPEX986   BM  114.8 PL  DeK Sheriff Sheriff (DeKalb, Sycamore)  FM  Law Tac
460.58750      WPEX986     DeK SD RF1 Sheriff: Receive Links to 154.01  FM  Law Tac
465.58750      WPEX986     DeK SD RF2 Sheriff: Receive Links to 154.01  FM  Law Tac
453.83750      WNWU479     DeKb Highway Highway Department   FM  Public Works
155.02500      KBX739   BM  CSQ  ESMARN ESDA: Statewide Highband  FM  Emergency Ops


TRT - Tactical Response Team

Conventional/Old Frequencies (still some use)


DCI - Department of Criminal Investigations

STARCOM21 Talkgroups

Description

Conventional/Old Frequencies (still some use)

  • F1 155.475 CSQ
  • F2 154.905 110.9 Statewide Dispatch
  • F3 154.950 CSQ Survellience
  • F4 155.460 CSQ
  • F? 156.000 CSQ Survellience
  • F? 154.650 127.3 Survellience
  • F? 151.160 Mobile Extenders
  • F? 460.450 Zone 6 Portable Repeater
  • F? 460.500 Zone 10 Portable Repeater
  • F? 156.115 Car-to-Car / Survellience
Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
154.90500  KA5825   110.9 PL  ISP DCI HF-2 DCI Zone Offices - Statewide (PL on mobile only) (HF-2)  FM  Deprecated
154.95000  KA5825   CSQ  ISP DCI HF-3 DCI Surveillance/Tactical (Car/Car) [HF-3]  FM  Deprecated
156.00000  KA5825   110.9 PL  ISP DCI 1560 DCI Local Enforcement/METRO  FM  Deprecated
155.44500      ISP D8 MCEG2 Multi-County Enforcement Group  FM  Deprecated
154.92000      ISP D8 MCEG1 Multi-County Enforcement Group  FM  Deprecated
154.69500  KWK444     ISP D8 PMRS District 8 PMRS  FM  Deprecated
154.90500  KWK444   CSQ  ISP DCI HF-2 District 8 PMRS  FM  Deprecated
155.46000  KWK444   CSQ  ISP S/W HF-4 District 8 PMRS  FM  Deprecated
154.65000      ISP DCI 5465 D15/DCI Local/SOS Car-toCar (HF-7)  FM  Deprecated
151.16000    110.9 PL  ISP DCI MX-1 DCI Mobile Extenders (not Southern IL)  FM  Deprecated
154.92000  KA5825   CSQ  ISP DCI 5492 DCI Local (PL on some)  FM  Deprecated
159.03000      ISP DCI 9030 DCI Local (reported in central IL)  FM  Deprecated
151.16000    146.2 PL  ISP DCI MX-2 DCI Mobile Extenders  FM  Deprecated
154.92000  KA5825   110.9 PL  ISP DCI 4.92 DCI: Car-to-Car/Surveillence  FM  Deprecated
154.95000  KA5825   110.9 PL  ISP DCI 4.95 DCI: Car-to-Car/Surveillence  FM  Deprecated
154.71000  KA5825   67.0 PL  ISP DCI 4.71 DCI? Mobile units   FM  Deprecated
163.65000    CSQ  ISP DCI WMic DCI Wireless Mikes  FM  Deprecated
165.28750    100.0 PL  MEG Ops Metropolitan Enforcement Group (Chi?)  FM  Deprecated
166.53750    100.0 PL  MEG Ops F2 Metropolitan Enforcement Group F-2? (Chi?)  FM  Deprecated


Secretary of State Police (SOS)

IL-sos police badge small.jpg SOS Badge IL-SOS Dist Map.jpg SOS District Map

11/02/07 - Now using StarCom21 for operations, dispatch is by the local ISP agency.

The department's investigators are trained in all aspects of law enforcement, with special expertise in auto theft investigations and vehicle-related consumer fraud. The department also maintains a Hazadous Device Unit (HDU)(Bomb Squad) that is used to recover and dispose of bombs. The Underwater Investigative Unit (UIU) conducts auto theft investigations with the waterways of the state, and investigators provide traffic safety training to other law enforcement agencies and the public. Also provides law enforcement for the State Capitol complex in Springfield.

  • District 1 - 405 Mannheim, Bellwood, IL 60104-1749, (708) 338-7555
  • District 2 - 4501 East State Street, Rockford, IL 61103-6904, (815) 987-7560
  • District 3 - 1800 East Adams, Springfield, IL 62703, (217) 785-5486
  • District 4 - 220 S. 12th Street, Mt. Vernon, IL 62864-3836, (618) 244-4525
  • District 4a - 1269 North 89th Street, East St. Louis, IL 62203-2134, (618) 398-7790

-Adminstrative Offices - 322 E. Adams -District 3 Headquarters - 1800 E. Adams (and Support Services Division, Vehicle Inspection Station) -District 6 (appears to be Capitol Police, SOS Security, Governors Security ?)

STARCOM21 Talkgroups

DEC HEX Mode Alpha Tag Description
4077  fed  SOS Z3S 4077  SOS: Operations (T325)
4079  fef  SOS Cap Disp  SOS: Capitol Complex: Security/Police (CapCom Springfield)
4080  ff0  SOS Cap Tac  SOS: Capitol Complex: Tac (Springfield)
4081  ff1  SOS Spfld Op  SOS: Operations (Springfield area)
4082  ff2  SOS Ops 4082  SOS: Operations
4083  ff3  SOS D3 c2c  SOS: District 3 - Car-to-Car ? (Carlinville)
4085  ff5  SOS Chi Sec1  SOS Security - Primary (Chicago SOS Drivers Facilities)
4086  ff6  SOS Chi Sec2  SOS Security - Alternate (Chicago SOS Drivers Facilities)
4089  ff9  SOS Ops 4089  SOS: Operations (Bloomington area)
4091  ffb  SOS D3 C2C  SOS: District 3: Car-to-Car
4093  ffd  SOS Ops 4093  SOS: Operations
4101  1005  SOS 4101 ENC  SOS: Operations [ENC]
4102  1006  SOS Ops 4102  SOS: Operations
4103  1007  SOS Ops 4103  SOS: Operations
4104  1008  SOS 4104 ENC  SOS: Operations [ENC]
4152  1038  SOS 4152 ENC  SOS: Operations [ENC]
4153  1039  SOS Ops 4153  SOS: Operations
4159  103f  SOS Ops 4159  SOS: Operations
DEC HEX Mode Alpha Tag Description
1226  4ca  SOS D1 Disp  SOS District 1: Dispatch
1227  4cb  SOS D1A c2c  SOS District 1: Car-to-Car A
1228  4cc  SOS D1B c2c  SOS District 1: Car-to-Car B
1229  4cd  SOS D1 1229  SOS District 1: Operations
1230  4ce  SOS D1 1230  SOS District 1: Operations
1231  4cf  SOS D1 1231  SOS District 1 :Operations
1232  4d0  SOS D1 1232  SOS District 1 :Operations
1233  4d1  SOS D1 1233  SOS District 1: Operations
1234  4d2  SOS D1 1234  SOS District 1: Operations
1235  4d3  SOS D1 1235  SOS District 1: Operations
1236  4d4  SOS D1 1236  SOS District 1: Operations
1237  4d5  SOS D1 c2c*  SOS District 1: Car-to-Car (Chicago Area)
1241  4d9  SOS D1 1241  SOS District 1: District 1 - Ops
1243  4db  SOS D1 1243  SOS District 1: Operations
1251  4e3  SOS D1 1251  SOS District 1: Operations [ENC]
1268  4f4  SOS D1 1268  SOS District 1: Operations
Description

Conventional/Old Frequencies (still some use)

Frequency  Input
License  Type  Tone  Alpha Tag  Description  Mode  Tag
155.92500      KTZ417   BM  218.1 PL  HF-8 (SOS) Car/Car (also IL Capital Police and Capital Security-Springfield)  FM  Deprecated
151.44500  159.37500   KA2864   RM    HF-5 (SOS) SOS North Repeater (tone varies)  FM  Deprecated
151.25000  159.42000     RM    HF-5 (SOS) SOS South Repeater (HF-5/6)  FM  Deprecated


Illinois Capital Police and Capital Security

STARCOM21 Talkgroups

Description

Conventional/Old Frequencies (still some use)

Frequency  License  Type  Tone  Alpha Tag  Description  Mode  Tag
155.92500  KTZ417   BM  218.1 PL  SOS CAPCOM IL State Capital: Maintenance (in use 3/13)  FMN  Public Works


Illinois Department of Natural Resources-IDNR

Illinois Conservation Police See Illinois_Department_of_Natural_Resources_(IDNR)_(IL)

10 Codes, Maps & Pager Tones

Paging Tones

ISP Alert Tone 2468.2/2137 (2155.6?)
ISPERN District 11 Tone 1049.9
ISP District 11/18 Weather Tone 2401.0/1781.5
Weather Alert Tone (42.5) 2440.0/1780.0
Situation Alert 2440.0/2840

10-Codes Used by most Illinois Agencies

10-0-Caution
10-1-Unable to Copy- Change Location
10-2-Signal Good
10-3-Stop Transmitting
10-4-Acknowledgement
10-5-Relay
10-6-Busy(Unless Urgent)
10-7-Out of Service
10-8-In Service
10-9-Repeat
10-10-Fight in Progress
10-11-Dog Case
10-12-Stand By
10-13-Weather(Road Report)
10-14-Prowler Report
10-15-Civil Disturbance
10-16-Domestic Problem
10-17-Meet Complainant
10-18-Quickly
10-19-Return To...
10-20-Location
10-21-Call(By Telephone)
10-22-Disregard
10-23-Arrive At Scene
10-24-Assignment Completed
10-25-Report in Person(Meet)
10-26-Detaining Subject
10-27-Drivers License Info
10-28-Vehicle Registration Info
10-29-Check for Wanted
10-30-Unnecessary Use of Radio
10-31-Crime in Progress
10-32-Subject with a Gun
10-33-Emergency
10-34-Riot
10-35-Major Crime Alert
10-36-Correct Time
10-37-Suspicious Vehicle
10-38-Stopping Suspicious Vehicle
10-39-Urgent(Use Lights & Sirens)
10-40-Silent Run
10-41-Beginning Duty
10-42-Ending Duty
10-43-Information
10-44-Permission to Leave
10-45-Animal Carcass at......
10-46-Assist Motorist
10-47-Need Road Repair At...
10-48-Traffic Standard Repair
10-49-Traffic Light Out At...
10-50-Accident(F,PD,PI)
10-51-Wrecker Needed
10-52-Ambulance Needed
10-53-Road Block At
10-54-Livestock On Highway
10-55-Intoxicated Driver
10-56-Intoxicated Pedestrian
10-57-Hit-Run(F,PD,PI)
10-58-Direct Traffic
10-59-Convoy or Escort
10-60-Squad in Vicinity
10-61-Isolate Self for Message
10-62-Reply to Message
10-63-Prepare Written Copy
10-64-Message for Local Delivery
10-65-Net Message Assignment
10-66-Message Cancellation
10-67-Clear for Message
10-68-Dispatch Information
10-69-Message Received
10-70-Fire Alarm
10-71-Advise Nature of Fire
10-72-Report Progress of Fire
10-73-Smoke Report
10-74-Negative
10-75-In Contact With
10-76-En Route
10-77-Estimated Time of Arrival(E.T.A.)
10-78-Need Assistance
10-79-Notify Coroner
10-80-Chase in Progress
10-81-Breatherlizer Report
10-82-Reserve Lodging
10-83-Work School Crossing
10-84-Meeting Advice
10-85-Delayed Due To...
10-86-Officer/Operator on Duty
10-87-Pick Up Checks
10-88-Telephone Number of...
10-89-Bomb Threat
10-90-Bank Alarm At...
10-91-Pick Up Prisoner/Subject
10-92-Improperly Parked Vehicle
10-93-Blockade
10-94-Drag Racing
10-95-Prisoner/Subject in Custody
10-96-Mental Subject
10-97-Check Signal(Test)
10-98-Prison/Jail Break
10-99-Wanted/Stolen Indicated

Related Wiki Pages

Images / Maps

Related Links

Search:IllinoisFTO


Copyright 2014 by RadioReference.com LLC Privacy Policy  |  Terms and Conditions
