STARCOM21 Usage

Site	Name	Freqs
001 (1)	Madison Co Simulcast (*)	851.350000	851.875000c	852.137500c	852.300000c	852.537500	852.775000	853.087500	853.662500

Site	Name	Freqs
059 (3B)	St. Clair Co Simulcast	851.075000	851.175000	851.225000c	851.562500c	851.700000	851.800000	852.087500	852.162500c
		852.587500	852.700000	852.750000	853.137500	853.637500	853.750000	853.850000	857.737500

Site	Name	Freqs
060 (3C)	Greenville	851.125000	851.587500c	852.800000a	853.250000a	853.725000

Site	Name	Freqs
012 (C)	Mount Olive	769.681250	769.718750	770.687500a	774.068750c	774.812500a	855.387500	855.737500

DEC	HEX	Mode	Alpha Tag	Description
7344	1cb0	D	Hamel Police	Hamel Police: Local Ops (Adam-36)
7345	1cb1	D	Worden Police	Worden Police: Local Ops (w/ Hamel)
8176	1ff0	D	Coll Fire / EMS	Collinsville Fire/EMS: Dispatch/Operations [CFD MAIN]
8177	1ff1	D	Coll FireEMS Ops	Collinsville Fire: Operations
8370	20b2	D	Hamel EMS	Hamel EMS [HAMEL EMS]
8391	20c7	D	St Jacob Fire	St Jacob Fire: Operations
8393	20c9	D	StJacob PubWorks	St Jacob Public Works
8461	210d	D	Godfrey Fire	Godfrey Fire
8462	210e	D	Godfrey Fire8462	Godfrey Fire: Ops
8463	210f	D	Godfrey Fire8463	Godfrey Fire
8551	2167	D	Coll Police EBT	Collinsville Police: Emergency Button Trigger
8552	2168	D	Coll Police Main	Collinsville Police: Main (Dispatch)
8553	2169	D	Coll Police C2C	Collinsville Police: Car-to-Car
8554	216a	D	Coll Police 8554	Colllinsvile Police: Ops
8555	216b	D	Coll Police 8555	Colllinsvile Police: Ops
8557	216d	D	Coll PoliceEvent	Collinsville Police: Events (Local)
8560	2170	D	Coll City 8560	Collinsville City: Ops
8561	2171	D	Coll Inspct 8561	Collinsville Inspectors/BN Service
8562	2172	D	GatewayCenter A	Gateway Center: Security / Ops
8563	2173	D	Coll Ops 8563	Collinsville: Ops
8575	217f	D	Collinsville EMA	Collinsville: EMA: Ops (CEMA) (CD units)
8676	21e4	D	Mad Roads 8676	unidentified Street/Roads Dept
8677	21e5	D	Mad Roads 8677	unidentified Street/Roads Dept
8678	21e6	D	Mad Roads 8678	unidentified Street/Roads Dept
8681	21e9	D	Mad Ops 8681	Operations (Madison City RIDs)

Glen Carbon PSAP (GlenCom)

Glen Carbon (Village) ^{WEB FB}

Dispatches Fire/EMS for Glen Carbon, Maryville and Troy. Pagers on VHF, Dispatch on STARCOM21 (Troy Fire response by Troy PD) Dispatches Police for Glen Carbon and Maryville on STARCOM21 [Note: Troy Police dispatched by Edwardsville Police, as of June 2023] As of summer 2023, GCPD also dispatches for Venice Police/Fire and Madison Police/Fire.

State-of-the-art, 24-hour telecommunications center. Officers are monitored via GPS and radio communications. Telecommunications also answers all incoming calls to the police department and serve as after-hour contact for all Villages of Glen Carbon and Maryville offices. As a PSAP, they receive 911 calls for Glen Carbon Police and Fire, Maryville Police and Fire, Madison Police and Fire, Venice Police and Fire, and Troy Fire Protection District. The center is also the Madison County Emergency Management and Metro East Crash Assistance Team activation point. (Note: Troy Police calls route to the Edwardsville PSAP)

The Glen Carbon Police Department is supported by a state-of-the-art, 24-hour telecommunications center. For their safety, officers are continuously monitored via GPS and radio communications. Telecommunications also answers all incoming calls to the police department and serve as after-hour contact for all Villages of Glen Carbon and Maryville offices. Uses New World CAD and LERMS.

Provides Free "Lockout" services for those that have locked keys in their personal vehicles

Glen Carbon Police Department ^{WEB FB Police Assn FB}

Police using Starcom21 since 2007 (The first police department in IL, outside of St Clair County, to start using STARCOM21)
18 officers; LIDAR (like RADAR) is used in city and on I-270.
12/8/09 - Upgraded their SC21 radio equipment, by installing Pyramid Vehicular Repeaters (See below) (Possibly no longer using due to simulcast sites going on air)
770.89375 M CSQ, 67.0 PL, 110.9 PL, 118.8 PL, 156.7 PL Police: Mobile Extenders (to SC21) [Expired 3/20] FMN WQLP241 (not heard in use anymore 3/13/24) removed from DB

FCC Licensing

Police mobile extenders to SC21, 770.89375/800.98375 Expired 3/20 (was confirmed in use before the simulcast Madison County site) WQLP241
155.055 IREACH for 10-110W Mobiles (no normal use) KB39310
former Police Repeater on 460.35 WNQA348 FCC Off Air by 2011. Was not narrowbanded.

Codes/Terms

Code 2 - possibly meaning Taser deployed (8/24)

Glen Carbon Fire Protection District/Ambulance District ^{WEB FB}

Serves: 15 square miles around the village limits. Became a Fire District in 1956. ALS Ambulances added in 2007. Glen Carbon EMS Article
Station 1 - 199 S Main - New station opened 7/21/2020
Station 2 - 430 Glen Carbon Rd - New station opened around 2000

Glen Carbon Public Works

Public Works: Truck 34 (154.995)

MONITOR AND ACTIVATE WATER DISTRIBUTION SYSTEMS

461.225 FXO 10W, Mitchell and Edwardsville WRAU333
461.225 FXO 10W, 6 Glen Carbon locations WQZV396
461.225 FXO 10W, 6 Glen Carbon locations WQZV397
461.225 FXO 10W, 6 Glen Carbon locations WQZV398
461.225 FXO 10W, 6 Glen Carbon locations (NW) WQZV399
461.225 FXO 10W, 6 Glen Carbon locations (SW) WQZV400

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
154.99500		KXM656	BM	CSQ	Glen PW/WaterB	Water / Public Works - Base	FMN	Utilities
453.12500	458.12500	WPYL839	RM	241.8 PL	Glen Siren Data	Outdoor Warning Sirens Data (Test 5am)	FMN	Data
154.99500		KXM656	BM	100.0 PL	Glen PW/WaterM	Water / Public Works - Mobiles	FMN	Utilities
770.89375		WQLP241	M	CSQ	Glen PD MX-O	Police: Mobile Extenders (to SC21) [Expired 3/20]	FMN	Law Dispatch
800.89375		WQLP241	M	CSQ	Glen PD MX-I	Police: Mobile Extenders (to SC21) [Expired 3/20]	FMN	Law Dispatch
462.11250		WQUT361	F		Glen PW Data	Public Works: Water Data (CSQ)	Telm	Data
461.22500		WQZV399	F		Glen PW Data 2	Public Works: Water Distribution Data (CSQ)	Telm	Data

Maryville (Village) ^{WEB MAP}

Police and Fire/EMS are dispatched by Glen Carbon Police dispatcher. (Fire/EMS toned out on 154.25, dispatch/ops on SC21)
Public Safety does have issues with STARCOM21 inside the Maryville Grade School
2020 Intergovernmental Agreement for dispatch with Glen Carbon Link
2/27/20 - The purchase of a VHF radio repeater from Wireless USA at a cost of $6,764 was also approved. A budgeted item, this replaces the phone line that transmits the radio signal from the Glen Carbon Police Department Dispatch Center to the base of the radio tower behind Maryville Village Hall to activate the firemen’s pagers. According to Deputy Fire Chief George May, the county was paying in excess of $900 per month to Call One for the use of this phone line and that the radio repeater will pay for itself in seven months. “The radio repeater will give us the ability to not have to use the phone line anymore,” he said.
155.88 10-110W mobiles KA57594 155.88 base KAS418

Siren System Upgrade (4/8/12)

Global Technical Systems Inc. submitted bids which included one that would essentially replace the system at a cost of $64,650
- Even with the $6,000 repair proposal, the village will be able to switch to a digital transmission system. That, then, will enable the Glen Carbon Police Department, which handles dispatching services for Maryville to activate the warning system, according to the Police Chief. Currently, Maryville’s system must be activated from inside the police station, which isn’t always easy when patrolmen are out at night.
- Maryville’s emergency warning system is tested at 10 a.m. on the first Tuesday of each month.

Maryville Police Department ^{WEB FB}

Police using Starcom21, see listings at the top of the page

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
155.88000		WZW728	BM	CSQ	Mv PubWrksO	(Old) Public Works / Water / Animal Control	FMN	Public Works
155.88000		KAS418	BM	146.2 PL	Mv Siren/PD	Emergency Siren Data / Police: Backup	FMN	Emergency Ops
464.81250		WQNF712	M		MaryvilleWDD	Water Data (CSQ)	Telm	Data
154.06250	159.07500	KA57594	RM	251 DPL	Mv PubWrksN	Public Works / Water <b>[No Longer on License]</b>	FMN	Public Works

Maryville Fire/EMS Protection District ^{WEB FB}

Units: 2400s. Serves 10,000 residents in 8 sq.mi. area, 1000 calls a year. 3 full time, 30 volunteer w/ 25 EMT/Paramedics

Saint Jacob (Village)

Police patrolled locally, by county and ISP. Dispatched on Troy Police talkgroup on STARCOM21
Formerly used Troy Police on 154.74 R 203.5 PL (after Troy went to SC21)

Saint Jacob (Township) Fire Protection District

Dispatched by County, Troy or Highland on county fire 154.4300 167.9 PL
154.430 WNGU348 St. Jacob TFPD Dispatch 1
154.265 WNGU348 St. Jacob TFPD Fireground 2

Troy (City) ^{WEB FB}

Troy Police Department ^{WEB FB}

Police uses Starcom21
18 officers

Former VHF Frequencies

153.74 former Police repeater output (203.5 PL???) w/ 153.935 input. Input deleted from license in 2008, but was still in use for some time.
156.045 is supposed to be the new input, but have not heard it in use at all. (*up to 8/4/09)
156.15 M Police: Tactical [Ch 2] (Old?) FMN Deprecated 2/3/25 KLU487

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
154.99500	153.96500	KLU488	RM	203.5 PL	Troy PublicWorks	Public Works: Water / Snow Plows (WNUK672 input Expired 9/15)	FMN	Public Works
154.25000	158.77500	KFA468	RM	CSQ	Troy Fire T/O PG	Troy Fire: Tone-Outs (from 158.775 GlenCom)	FMN	Fire Dispatch

Troy Fire Protection District ^{WEB FB}

Paged out by Glen Carbon Police.
ISO 3, 30+ volunteers, 8 apparatus. Serves 65 square miles, nearby I-70, 55 and 270, around the city of Troy. Average of 250 calls per year (*OLD)
2 ALS Ambulances
154.25, 154.43 45W Bases with 30-45W mobiles. Mobiles on 155.16 MERCI160 Base, 40-45W mobiles on 155.34 MERCI340 KFA468

Troy Public Works

Units: 512,514,543,553,555,602 Water Office
154.995 203.5 PL is Public Works repeater output, but KLU488 is licensed only as Base/Mobile; 153.965 is repeater input on license WNUK672 Expired 9/15
- still heard in use, full scale in Glen Carbon, by snow plows (1/25)

Pontoon Beach (Village)

Pontoon Beach Police Department ^{WEB FB}

Uses STARCOM21 for main communications
Formerly used 155.79 Base/Mobile D271 (formerly CSQ) WNJM746 Deprecated 2/3/25
There is also a large "Command Center" vehicle and 3 Police Emergency Response Unit trailers sitting at the Municipal Building.
Employs 22 people on its police force, including four dispatchers and a records clerk. Uses ISP TIPS codes.

159.4575 110w Repeater with 156.0675 input (NFM) 25-110w mobiles (Never heard in use) WNJM746
159.4575 156.0675 WNJM746 RM CSQ PntnBch Local Local FMN Deprecated 2/3/25, unsure if ever used,
7/23 add: 155.85 50w Repeater with 158.91 input (NFM) D261 10-50w mobiles WNJM746 Have only heard Outdoor Warning Siren Data

Long Lake Volunteer Fire Department (Pontoon Beach) ^{WEB FB}

Units are 2100s. Dispatched on County Fire 154.43 167.9 PL by Madison County 911, Pontoon Beach or Edwardsville; has local fireground repeater (as of 2021)
Serves 12,000 people in 12 sq mi.; Automatic mutual aid with Mitchell (serves Pontoon Beach and unincorporated Nameoki Township)
EMS provided by Rural Med EMS - Metro East as of 4/1/23
Has a channel called "Command 2" (12/24)

Pontoon Beach Public Water District

Unknown communications

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
151.00250	159.25500	WREZ552	RM	734 DPL	Long Lake Fire	Long Lake Fireground [can Simulcast to SC21 TG7913]	FMN	Fire-Tac
155.85000	158.91000	WNJM746	RM	265 DPL	PonBch SirenData	Outdoor Warning Siren (DTMF)	FMN	Emergency Ops

Mitchell (Unincorporated)

Law by Sheriff

Mitchell Volunteer Fire Department ^{WEB FB}

Paged by county or Glen Carbon PD on SC21 Fire South (as of 1/25)
~~Paged on 154.43 by County or Pontoon Beach Dispatch, local (firehouse) dispatch on calls~~
Units: 1100s -- Serves: Area between Hartford Canal on the north, Chouteau and Nameoki Township lines on the south, Illinois and Missouri on the west and near the Bluffs on the east.

Automatic Mutual Aid with Long Lke FPD, also Mutual Aid with Edwardsville, Granite City. Became a FPD in 1949.

BLS Non-Transport EMS/Rescue; EMS provided by Rural Med EMS - Metro East as of 4/1/23
154.295 KLS473 BM CSQ (Old) Fire: Local / Fireground (still CSQ 11/17) FMN Deprecated 2/3/25

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
155.65500	159.40500	WRBL600	RM	167.9 PL	Mitchell Fire	Fire: Tone-Outs/On-Scene [Patch to SC21 TG7913 Fire South]	FMN	Fire Dispatch

Madison (City)

Madison Police/Fire 911 calls taken by Glen Carbon and transferred to local dispatch. Glen Carbon dispatch pay be heard on talkgroups.

Madison (city) Police ^{WEB FB}

Police using Starcom21, see listings at the top of the page

~~Old licenses - 158.8950 KE8526 & 158.7450 KN2858 NO LONGER IN USE~~

Frequency	License	Type	Tone	Alpha Tag	Description	Mode	Tag
155.88000	KAS418	BM	CSQ	Madison Fire	Fire/Rescue: Tone-Out / Street Dept / Venice Fire	FMN	Fire Dispatch

EMS by MedStar

Madison Fire ^{WEB FB} Serves: Madison, unincorporated Venice and parts of Nameoki Township

Madison Public Works

Refuse Units: 3,5?? 155.88 ?? "Madison Base" Truck 8, Street 31 (this may have been Granite City units, unknown)

Venice (City)

Police/Fire 911 calls taken by Glen Carbon PSAP and transferred to local dispatch. Glen Carbon dispatch pay be heard on talkgroups.

Venice Police

Began using STARCOM21 as of 8/22

Venice Fire ^FB

Serves the city limits of Venice. 155.88 still in use for paging (only?) as of 8/16/22

Frequency	License	Type	Tone	Alpha Tag	Description	Mode	Tag
155.07000	WQPJ991	BM	411 DPL	Venice Police	(BACKUP TO TRS) Police: Dispatch	FMN	Law Dispatch
155.88000	KDR695	BM	CSQ	Venice Fire	Fire: Tone-Outs / Dispatch (9pm Page Test)	FMN	Fire Dispatch

EMS provided by AMR Abbott EMS

Wood River Central Dispatch PSAP

2/24 - most departments have switched to DMR VHF Repeaters. Radio ID's will be updated in the future. (RIDs)

Wood River now dispatches for:

FIRE - East Alton, Wood River, Hartford, South Roxana, Roxana; 154.145 is Paging, 153.785 is Command/Fireground for all departments (Tac 2) (NO licensed base stations)
POLICE - Wood River, East Alton, Hartford, South Roxana, Roxana on 155.115; Bethalto is dispatched on their NXDN frequencies Article - WR to dispatch 6 cities for Police
Backup PSAP is Alton Police

Communications issues 2019 LINK Alton Telegraph Article

Interim Coordinator Burris introduced Wood River Fire Chief Brendon McKee. Chief McKee gave a presentation on radio needs and communication issues. He introduced Cory
Heuchert from Edwardsville Fire and Stan Foiles with DataTronics for any technical questions. He reported that after the East Alton PSAP consolidated with the Wood
River PSAP the surrounding areas have had increased problems with radio communications. He spoke on: safety issues for fire and police personnel; technical issues; interoperability
issues; possible solutions such as a voter analog system, Starcom21, and a pilot program for a digital radio system; and costs. He asked the ETSB to be receptive of supporting a digital
radio system in the immediate area (Wood River, East Alton, Bethalto, etc.) for use as a pilot program to then eventually implement across the County. The cost and scope of the project
is still being evaluated. Mr. Petrokovich confirmed the issues the Wood River area is experiencing and spoke on radio communication needs to backup PSAPs

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
153.78500		WPCM483	BM	192.8 PL	WdRvr Fire Cmnd	Command/Fireground [Tac-2]	FMN	Fire-Tac
154.14500		WNYJ377	BM	107.2 PL	WoodRiver FirePG	Fire: Tone-Outs (Station Pages)	FMN	Fire Dispatch
155.71500		WSL817	BM	CSQ	WdRvr PubWorks	Public Works/Township Road Maintenance [Expired]	FMN	Public Works
456.10625		WQHF458	F		WdRvr WDD2	Water Distribution Data	Telm	Data
453.83750		WQHM978	F		WdRvr WDD1	Water Distribution Data	Telm	Data
151.49750	157.65750	WPPZ806	RM		WR EA HF RX Fire	Fire: Command	DMR	Fire Dispatch
155.11500	155.71500	KDX509	RM		WoodRiver Police	Police: Dispatch 1	DMR	Law Dispatch
155.11500	155.71500	KDX509	RM		WoodRiver PD 2	Police: Dispatch 2	DMR	Law Dispatch
155.11500		KDX509	M		WoodRiver PD T/A	Police: Direct/Talk-Around	DMR	Law Tac
151.02500	158.94750	WNYJ377	RM		WoodRiverFireNew	Fire: New	DMR	Fire Dispatch

Bethalto (Village) ^{WEB FB}

Police and Fire dispatched by Wood River PSAP (as of 2/21)

WRPD uses 156.1725 (input to Repeater) 45 RAN to reach the Bethalto Police Repeater and can be heard through-out the area (Encrypted)

Bethalto Police Department ^FB

Animal Control
Police using NXDN since Summer 2018 (formerly used SC21 talkgroups)
Radio IDs for 151.235 - 1, 2, 4, 6, 7, 112, 229, 1111, 1500 (on TG1 11/14/23)
- RIDs 101 SECRETARY, 104, 223 BUS#23, 1500, 6212 (1/25) (School?????)
158.805 Repeater (w/156.0 in) 179.9 PL was being used as Simulcast of 151.235 NXDN TG1FMN KUN481
CONFIRMED still simulcasting Police, and Fire Pages (as of 8/23/24)

Bethalto Fire Department ^{WEB FB}

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
158.92500		KUN481	BM	206.5 PL	Bethalto PubWork	Public Works	FMN	Public Works
158.92500		KUN481	BM	146.2 PL	Bethalto Water	Water Department	FMN	Utilities
151.49000	154.31000	KRA500	RM	143 DPL	Bethalto Fire PG	Fire: Tone-Out/Dispatch (in use 5/4/24)	FMN	Fire Dispatch
151.23500	156.17250	KUN481	RM	45 RAN	Bethalto PoliceD	Police: Dispatch [TG 1]	NXDN48	Law Dispatch
151.11500	154.88250	KUN481	RM	50 RAN	Bethalto Police2	Police: Secure [TG 2]	NXDN48	Law Tac
154.79250		KUN481	BM	156 DPL	MadCo Sheriff *P	Sheriff: Dispatch (Rebroadcast SC21 TG)	FMN	Law Dispatch
151.23500	156.17250	KUN481	RM	45 RAN	Beth Police TG3	Police [TG 3]	NXDN48	Law Tac
151.11500	154.88250	KUN481	RM		Bethalto FireDMR	Fire: Tone-Out/Dispatch - New	DMR	Fire Dispatch
158.80500	156.00000	KUN481	RM	179.9 PL	Bethalto PoliceA	Police: Simulcast of 151.235 NXDN TG1 / Fire Pages (8/24)	FMN	Law Dispatch

Serves: Moro (Mutual Aid to Cottage Hills, Meadowbrook cover Bethalto) M/A Agreement with Meadowbrook-will dispatch at least one pumper/manpower to back-up Bethalto
ALS Non-Transport
(former use) STARCOM21 talkgroups 8351 - 8354. Now using VHF.
(former use) 154.175 BM 114.8 PL Fire: Old [Abandoned 4/12] FMN KRA500

EMS

Provided by Bethalto Rescue, Alton Memorial EMS

Bethalto Public Works

Street Department Units: Truck 4
464.15 10W Fixed for NFM Water Distribution Data WQSW924

Cottage Hills (Unincorporated) ^{WikiPedia Info}

Law by Madison County Sheriff (w/ backup by Bethalto Police and Illinois State Police)
EMS Provided by Alton Memorial Ambulance
451.1375 for Water Data (4/12) American Water Works Service Company WQOV283

Cottage Hills Fire Protection District ^FB

Dispatched on 154.43 by Madison County 911
Serves: Cottage Hills, Forest Homes, Zepher Ridge
Mutual Aid agreement with Bethalto Fire, Meadowbrook Fire, Cottage Hills Fire to respond to all fire calls within those districts as first alarm assignments.

Frequency	License	Type	Tone	Alpha Tag	Description	Mode	Tag
154.28000	KBF257	B	CSQ	CottageHills FG	Fireground	FMN	Fire-Tac

East Alton (Village) ^{WEB FB}

East Alton Police Department ^FB

155.43 154.71 RM 192.8 PL E Alton Police Police: Secondary/Back-Up (in use?) FMN KSC756 Expired 9/23 Deprecated 8/23/24
Dispatched by Wood River PSAP on Bethalto Frequency (ENCRYPTED)

East Alton Fire Department ^{WEB FB Union FB}

BLS Non-Transport EMS/Rescue
Units: 4200s; Response area of 10 sq.mi, large part includes Olin Manufacturing.; Uses the Wood River Fire Protection District frequencies

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
155.43000	154.71000	KSC756	RM	192.8 PL	E Alton PoliceBU	(BACKUP) Police: Secondary <B> [Expired 9/23; in use 2/25]	FMN	Law Dispatch
154.98000		KNDD717	BM	192.8 PL	E Alton PubWrks	Public Works / Water [Expired 8/02]	FMN	Public Works

EMS

Primary: Alton Memorial AMH Ambulance, Secondary: Alton Fire/EMS 3) Backup: AMR Abbott EMS (if available) Link

'"East Alton Public Works'

Street Division, Water Division and Sewer Division
Units heard: #3,30, "Water Plant"

Hartford (Village)

Harford Police Department ^{WEB FB}

Frequency	License	Type	Tone	Alpha Tag	Description	Mode	Tag
155.89500	KKR357	BM	CSQ	Hart PW/Loc	Public Works / Police: Local	FMN	Public Works

Hartford Fire Department ^{WEB FB}

Units: 3800s (former 400s)

Rosewood Heights (Village)

Police by Madison County, back-up by Bethalto and Wood River Police

Rosewood Heights Fire Protection District

Roxana (Village) ^WEB

Roxana Police Department ^{WEB FB}

Roxana Fire Department ^{WEB FB'}

Uses the Wood River FPD frequencies; part of WRFPD
1 station on West 3rd Street and covers approximately 12 square miles. Contracted with Kendall Hill subdivision for emergency services, responds for automatic mutual aid with South Roxana Fire Protection District, and, as requested, to Conoco Phillips Refinery to support their Emergency Response Team.
Units: 2500s; 3 full-time firefighters and a paid-on-call roster of 15 firefighters.

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
153.81500	155.98500	KA91441	RM	225.7 PL	Rox PW1/PD2	Police: Tac [Ch 2] / Public Works [Ch 1]	FMN	Multi-Tac

South Roxana (Village)

South Roxana Police

Dispatched by Woodriver ????

South Roxana Fire Protection District ^FB

Serves: South Roxana and the surrounding rural area.
Units: 3100s; Uses the Wood River FPD frequencies
BLS Non-Transport EMS/Rescue

~~153.860 WNAS645 B Fireground (Never heard) [Expired] FMN~~

Wood River (City) ^WEB

Wood River Police ^{WEB FB} DMR Radio IDs

10 Dispatcher
167 ?
174
685 Roxana unit ?
1280
1370 Roxana 1?
1970
2401
9112
9161
9164
9165
9166 unit 66
9167 unit 167 WRPD
9171
9174
9200
13701
17001 unit 170 // Roxana 1?
47001 unit 170 Portables
99685 unit 85
969903 ??

Code 1 = Secure ??

Wood River Fire Protection District ^{WEB FB}

Units: 4200s; Serves: City limits and a rural contracted areas, 11300 people in 6 sq miles in Wood River, Hartford, Roxana, South Roxana
Paging Dispatched [Wood River Fire/HazMat/Rescue/Regulars/Engine 73] [South Roxana Fire] [Roxana Fire/Roxana Regulars "Central Station"] [Roxana Medical Emergency] [Hartford Fire]
Wood River Central Station - 501 Old Edwardsville Road (Opened in 1997)
Station 1 - Truck 13-Snorkel/Pumper, Truck 14 Rescue/Pumper (has "Mobile Encoder" to page out fire) Unit 10 - Chief ?
Pages/Dispatches: Wood River Fire, HazMat, Rescue, Regulars, Engine 73; South Roxana Fire; Roxana Fire/Roxana Regulars; "Central Station; Roxana Medical Emergency; Hartford Fire
DMR RIDs - 311005 unit 3110

Wood River Public Works

Units Heard: 15,30,51, C52, C57

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
153.78500		WPCM483	BM	192.8 PL	WdRvr Fire Cmnd	Command/Fireground [Tac-2]	FMN	Fire-Tac
154.14500		WNYJ377	BM	107.2 PL	WoodRiver FirePG	Fire: Tone-Outs (Station Pages)	FMN	Fire Dispatch
155.71500		WSL817	BM	CSQ	WdRvr PubWorks	Public Works/Township Road Maintenance [Expired]	FMN	Public Works
456.10625		WQHF458	F		WdRvr WDD2	Water Distribution Data	Telm	Data
453.83750		WQHM978	F		WdRvr WDD1	Water Distribution Data	Telm	Data
151.49750	157.65750	WPPZ806	RM		WR EA HF RX Fire	Fire: Command	DMR	Fire Dispatch
155.11500	155.71500	KDX509	RM		WoodRiver Police	Police: Dispatch 1	DMR	Law Dispatch
155.11500	155.71500	KDX509	RM		WoodRiver PD 2	Police: Dispatch 2	DMR	Law Dispatch
155.11500		KDX509	M		WoodRiver PD T/A	Police: Direct/Talk-Around	DMR	Law Tac
151.02500	158.94750	WNYJ377	RM		WoodRiverFireNew	Fire: New	DMR	Fire Dispatch

Municipalities and Districts

Townships

Assumed to be no longer in use, 151.025 is new WR Fire Repeater output

151.025 WNVN435 BM 210.7 PL Chouteau Township Roads [Expired] FMN Deprecated 8/9/24
151.025 BM 136.5 PL Foster Township: Roads FMN Deprecated 8/9/24

Collinsville Township ^WEB

Comprises 36 sq.mi.s and includes all of the Madison County portion of Collinsville, all of Maryville, and a small part of Glen Carbon and Pontoon Beach
Road Department - unknown radio usage, Unit "C-51" truck had what looked like a VHF whip on side mirror area.
- Update 1/07 - Confirmed a UHF antenna on top of truck (center loaded). Could be using a KLL or Warner repeater or LTR.
Senior Citizens Center - Located on Main St in Collinsville
Folks Wagon/Senior Shuttle ^WEB
Shopping, Dr Appts, etc. and Weekly field trips

464.225 110.9 PL - unidentified Township ops? - Snow Plowing on Wagner, Buffalo Roads (Marine and/or Alhambra Townships), talk about 143 and another road that the state has not done. Repeater located in troy (Pin Oak Township)

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
154.11500		WQA758	BM	118.8 PL	EdwTwp Roads	Edwardsville Township Road District	FMN	Public Works
155.10000		KDA985	BM		GodfreyTwp Road	Godfrey Township: Roads	FMN	Public Works
154.04750		KNIG943	BM	136.5 PL	FtRusslTwp Road	Fort Russell Township: Roads [Expired 4/04]	FMN	Public Works
154.11500		KNDU336	BM	CSQ	NamkTwp Road	Nameoki Township Roads [Term 2002]	FMN	Public Works
456.05000		WPMA349	F	103.5 PL	TriTwp Water	Tri-Townships Water District	FMN	Data
155.08500		KFX582	BM		ME Sanitary Dist	Metro East Sanitary District: Ops [Expired]	FMN	Public Works
153.57500		WQYD378	BM		NEC Water	North East Central Water District	FMN	Utilities
956.34375		WQHT678	F		BMW WDD A	Bond-Madison Water: Data	Telm	Data
153.53750		WPNY502	F		BMW WDD B	Bond-Madison Water: Data (Marine, Livingston) (CSQ)	Telm	Data
464.22500	469.22500	KNGM587	RM	110.9 PL	Marine Twp Roads	Marine Township: Roads	FMN	Public Works
151.07750		WRBW717	BM		WdRiv Twp Roads	Wood River Townshp Roads (Cottage Hills)	DMR	Public Works
463.73750		WQVD372	F		NECWD Data	Northeast Central Water District: Data (CSQ)	Telm	Data

Water, Sewer and Levee Districts

Wood River Drainage and Levee District

District officials are looking at a total renovation for the levee, including pump stations, relief wells, turn gates and other structures. -- Unknown communications.

Alhambra (Village)

Alhambra Community Fire District ^{WEB FB CERT FB}

Units: 3200s; Serves 10 square miles.
154.4300 167.9 PL Local Test Page 6pm)
Former dispatch, now on 151.1825R D243/159.1725 (D152 input)

Alhambra-Hamel Ambulance Service

Alton (City) ^WEB

154.8075 DMR

TG200 Heard "out there working very aggressive pitbull" (4/19/24) Animal Control???

RIDs

1, 194, 201, 502 (used during Parade ops 2024) TG100 TG200 SL1

8/16/17 - City to Upgrade All Radio Systems Link

Alton Police Department ^{WEB WEB}

The Alton City Jail has 27 adult jail cells, 2 juvenile cells, and 4 holding cells. Many cells are double-bunked, creating a capacity for up to 53 inmates

Police DMR Radio IDs

20 Dispatch
327 Car 7
705 Sam 1 (1/24)
1103 Ocean 1 (1/24)
1204 David 2 (1/24) (Detectives?)
1601 Detective unit
1807 David 6 (1/24) (Detectives?)

David 4

~~155.19 NXDN 9600 RAN19 - Primary Channel OLD~~

RIDs: 172, 184 [0184], 316 [0316], 701 [0701] 1202 (updated 12/21)

FORMER 2/16 - 155.19 Repeater still on air, has some use (Motorola Securenet available for use on repeater and simplex -Unknown if this is still available); 158.835 no longer on air?, 154.085 (still in use 12/13) [both deleted from license]

6/20 155.6325 is a Backup. They are testing different modes including NXDN and DMR. DMR could Possibly have the big E.

~~Handhelds are NXDN and Mobiles are DMR~~
Back-up PSAP for Wood River

former use

155.190 156.030 WNJE317 RM 14 RAN (OLD?) Police: Dispatch (Simulcast of 155.6325) NXDN96 Deprecated from DB 4/19/24
155.6325 159.0225 WNJE317 RM 047 DPL (OLD?) Police: Dispatch FMN Deprecated from DB 4/19/24
155.190 156.030 WNJE317 RM 156.7 PL Police: Tac FMN Deprecated from DB 4/19/24

Alton Fire Department / EMS ^{WEB FB UNION FB}

Now providing secondary EMS to East Alton (primary is AMH) (as of 8/18)
EMS service began in Apr 2017 with 2 units, serving only the city limits. LINK The city would only provide transport from the scene to local hospitals, however. Inter-facility transports, like from nursing homes to hospitals and from hospital to hospital, will not be done by the city ambulance service under this plan.
LifeStar serves the west side of town and Alton Memorial Ambulance serves the east half of Alton.
Station 1: Don Twitchell Memorial Station - 333 E. 20th Street
Station 2: 3212 College Avenue

Alton Public Works

1.4 PL Public Works - Streets / Zoning-Inspectors / Water Department / Snow Plows
- Units: 4 (dispatch), 43, 44, 221, 223

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
154.38500	159.06000	KDR424	RM	156.7 PL	Alton Fire/EMS	Fire/EMS/Rescue: Dispatch / Operations	FMN	Fire Dispatch
158.97000		KNNU219	M	156.7 PL	AltonPolice c2c3	Police: Tactical / Car-to-Car [Ch 3]	FMN	Law Tac
153.75500		KNNK341	M		Alton PW Site 1	Public Works: Job Sites [67.0?]	FMN	Public Works
153.93500		KNNK341	M		Alton PW Site 2	Public Works: Job Sites	FMN	Public Works
154.95750	153.86750	KSH507	RM	151.4 PL	Alton PublicWork	Public Works	FMN	Public Works
154.77750		WQLI552	M		Alton Marina	Marina Security (D243?)	FMN	Security
154.80750	153.97250	WNJE317	RM		Alton DMR Fire	(Reserved) Fire	DMR	Multi-Dispatch
154.80750	153.97250	WNJE317	RM		Alton Citywide	Citywide Aid / Animal Control / Events	DMR	Multi-Dispatch
154.80750	153.97250	WNJE317	RM		Alton DMR 77199	(Reserved) Public Safety	DMR	Multi-Dispatch
154.80750	153.97250	WNJE317	RM		Alton DMR 101	(Reserved) Public Safety	DMR	Multi-Dispatch
154.80750	153.97250	WNJE317	RM		Alton DMR 201	(Reserved) Public Safety	DMR	Multi-Dispatch
154.80750	153.97250	WNJE317	RM		Alton DMR AllCal	(Reserved) Public Safety	DMR	Multi-Dispatch
155.63250	159.02250	WNJE317	RM		Alton Police DMR	Police: Dispatch	DMR	Law Dispatch

Marine License for 156.45, 156.575, 156.78 WQXH438

154.08500 KSH507 BM 151.4 PL Public Works [Deleted*] FM Expired/Deleted from license, confirmed still in use 1/19/10

158.83500 153.87500 KSH507 RM 156.7 PL Animal Control [Deleted*] FM

~~453.73750 KB26071 M Parks / Recreation [Expired] FMN~~

Brighton (Village)

Located in Jersey and Macoupin Counties (north of Godfrey). Brighton-Betsey Ann FPD is ALS Non-Transport. Dispatched on local frequencies by Mac911/Jersey County 911

Brooklyn (Village)

Located in St Clair County, using STARCOM21, but near Venice and Madison in Southwest Madison County

Collinsville (City) ^WEB

A major portion of Collinsville is located in Madison County. A small portion is located in St Clair County. Cahokia Mounds is technically is the city boundaries and served by Collinsville Fire/EMS. Some township areas, such as State Park township, may have Collinsville addresses.
IREACH: 155.055 50-45W mobiles KB90595
Senior Citizens Shuttle - 458.55 4-40W mobiles WNAH538
Trash/Recycling is contracted to Republic Services

Collinsville Police Department ^{WEB FB}

45 officers with bodycams (as of 2023)
IWIN MDT's are used in cars
Code 9 = (Appears to mean) Secure

Collinsville Communication Center/Telecommunications

8 Full-Time, 2 Part-Time Dispatchers (2023) Article on 911
6/24 - Dispatch is currently under construction Article
Expanding from 2.5 dispatch stations to 4, adding a supervisors office. This is the second remodel of the center since it opened in 2000. New furniture for the dispatchers.

Responsible for 911 and non-emergency call taking and dispatching for Collinsville Police, Fire, and EMS and Animal Control. The telecommunicators achieve and maintain the following accreditations and licenses: 911, CPR, EMD, LEADS, IDPH, and REJIS

Can contact St Clair County PSAPs, etc. on St Clair County Calling talkgroup on SC21
In 2023, received 10,824 calls to 911, processed 31,637 Police calls for service; and 4,374 EMS/Fire calls for service.

465.1 D612 is being heard in the St Louis area, unknown at this time (12/23)

460.1R KSA903 RM 026 DPL Collinsville Police: Dispatch [Ch 1/2] (Simulcast SC21 TG8552) FMN (former use as of 3/21)

460.275 KSA903 M CSQ Coll Police c2c6 Police: Tactical/Car-to-Car [Ch 6] FMN Deprecated (Removed from DB 3/13/24)

~~465.275 KSA903 B CSQ Coll Police c2c7 Police: Base-to-Car (on 460.275) [Ch 7] FMN Deprecated (Removed from DB 3/13/24)~~

"'Patrol Division

When fully staffed, made up of 30 officers, broken down into four patrol squads, led by a patrol sergeant. Additionally, we maintain two K-9 teams that are assigned to two of the patrol

squads. The typical patrol shift is 12 hours and alternates from days to nights every six weeks. Investigations Division

4 investigators and a Detective Sergeant. Also, home to patrol officers who are working assignments outside the Department, such designations include a special agent assigned to the Metropolitan Enforcement Group of Southern Illinois (MEGSI), a task force officer assigned to the Drug Enforcement Agency (DEA), as well as three School Resource Officers (SRO) who work within our school district.
One SRO is assigned to Collinsville Middle School, one is assigned to Collinsville High School, and our new SRO acts as a roving SRO amongst Dorris Intermediate School and our

elementary schools.

Collinsville Fire/EMS ^{WEB FB}

Units: 1200s. Assigned as "1800 units" for St. Clair County, but not used)
Station 1 - 125 S. Center (Downtown)
Station 2 - 1160 Belt Line Road (North Side FPD)
- New Station 3 being built at Pine Lake Rd, behind CVS

See STARCOM21 RIDs for more information
154.355 is also used for the Outdoor Warning Sirens (verified 7/22)
6-110W mobiles on 155.16, 155.22, 155.34 for EMS/Patient Reports KW7279
Fire (Scene of Action) 769.54375, 770.26875, 770.61875, 770.896875 (P25/Narrowband) WQPP944
Code 9 - Status Heard from Medic 42 (2/25)

Former VHF Actual Radio Layout

<s>
155.6700             KSA903  BM      CSQ  Collinsville EMA: Local
154.3550  159.7750   WPII568 RM  91.5 PL  Collinsville Fire/EMS: Dispatch - Main
159.9750             WPII568  M      CSQ  Collinsville Fireground
150.7900             WPII568  M           Collinsville Fire: Mobile Extenders
154.3550  159.7750   WPII568 RM  91.5 PL  Collinsville Fire/EMS: Dispatch [1-FD Main]
154.3550             WPII568  M  91.5 PL  Collinsville Fire/EMS: Talk-Around [2-Fire Talk]
158.8050             WNAH538  M      CSQ  Collinsville Public Works     [3-Public Works]
154.4300             WPII568  M 167.9 PL  Madison County 911            [4-Madison Co]
154.1900             KSF817   M 186.2 PL  St. Clair County 911 Dispatch [5-St Clair Co]
154.1750  156.1950   WQBA905  M 210.7 PL  Edwardsville Fire             [6 Edwardsville FD]
154.2500             KFA468   M  94.8 PL  Troy Fire Department Dispatch [7-Troy-FD]
154.2650             WPII568  M 210.7 PL  Fire: Statewide Mutual Aid    [8-MABAS]
153.8300             WQAG579  M  69.3 PL  MABAS Fireground - Red        [9-FG-RED]
154.2800             WQAG579  M  74.4 PL  MABAS Fireground - White      [10-FG-WHTIE]
154.2950             WQAG579  M  85.4 PL  MABAS Fireground - Blue       [11-FG-BLUE]
154.2725             WQAG579  M  94.8 PL  MABAS Fireground - Black      [12-FG-Black]
153.8375             WQAG579  M  91.5 PL  MABAS Fireground - Gold       [13-FG-Gold]
162.5500                      M      CSQ  National Weather Service - St. Louis [14-Weather]
159.9750             WPII568  M      CSQ  Collinsville Fireground       [15-Fireground]
150.7900             WPII568  M           Collinsville Fire: Mobile Extenders [16-Repeater]

Collinsville Emergency Management

Utilizes the CodeRed Emergency Communications (Notifications) system. ^{City WEB CodeRed WEB}
Using STARCOM21 talkgroup xxxx for primary communications (as of 2024)

~~154.355 Repeater with 159.775 input RM 91.5 PL (Former Fire Dispatch) WPII568 Appears to be no longer in use for voice (2024)~~
Note: 159.775 is confirmed, but NOT a valid frequency and NOT listed on the license. The license lists 159.975 mobiles and FX1
Also licensed for 150.79 1-10W Mobile Extenders, 30-2.5W portables 154.43 Base/Mobiles for County Fire, 154.265 Base/Mobiles for IFERN Mutual Aid
154.355 186.2 PL is being used for Outdoor Warning Siren data, not being heard on 159.775 or 159.975. Varying signal strengths of data bursts. (4/24)

The replacement of the City's outdoor warning system is nearing completion! 4/19/24
The system that's being replaced – which had been in place for decades and included sirens that were over 40 years old – used a manually-activated process that required City Communications Technicians to receive information of a tornado warning via a teletype or email, acknowledge that they had the information and set off ALL of the City's sirens at once from the Communications Center located in the Police Department. Because of their age, replacement parts were no longer available for these sirens and their failure rate was high.

Instead of relying on manual activations, the new siren system uses more advanced technology that’s connected to the National Weather Service’s polygon warning system, which improves accuracy and quality. According to the NOAA and NWS, this allows your local NOAA NWS Weather Forecast Office to "be able to narrow their focus on a portion of a county (or counties) that have the greatest threat for being impacted by severe weather." Once a tornado warning is issued for a polygon-based area, the sirens that are in said area automatically activate – NOT all of the City's sirens. If the siren(s) in your area sound, a tornado or destructive thunderstorm is projected by the NWS to be heading in your direction.

To date, seven sirens in the City's portion of Madison County have been replaced. The remaining five Madison County sirens are expected to be replaced by the end of April. Additionally, all but one of the sirens in the City's portion of St. Clair County have already been replaced – with the lone outdated siren expected to be replaced soon.

The new sirens are solar-powered and driven by technology. While the distance the sound carries from a new siren is further than with the legacy system, it's worth noting that the new sirens have a bit of a different sound. It's also important to note that with both the new sirens as well as the ones being replaced, an outdoor warning system is designed to be heard outdoors only.

16 new outdoor sirens have been installed over the last 12 months, replacing a 1980s vintage system that had to be triggered manually. The system automatically interacts with the National Weather Service. Only sirens within the NWS polygons will go off, not all of them. Fox2now LINK

Collinsville Public Works ^WEB

158.805 heard; "Water Plant" to "24",Sweeper, Unit 10?? 505 (from Coll PD) respond to a dog problem WNAH538

Collinsville Area Recreation District (C.A.R.D.)^WEB

See.....

Gateway Convention Center/Collinsville Metropolitan Exposition Auditorium and Office Building^{WEB FB}

~~158.895 previously reported as D754, but confirmed as D466 Operations (1/09)~~ Now using NXDN on UHF portables
55-5W 452.5375, 452.1875, 451.7125, 456.5375, 452.9875, 451.5375 (NXDN) (New 2017) WQZE984

~~158.895 WNVB343 M 466 DPL Gateway Center: Ops [Ch 1] [Expired 6/14] FMN Deprecated (Removed from DB 3/13/24)~~

~~158.940 WNVB343 M Gateway Center: Ops [Expired 6/14] FMN Deprecated (Removed from DB 3/13/24)~~

Frequency	License	Type	Tone	Alpha Tag	Description	Mode	Tag
158.80500	WNAH538	BM	CSQ	Collnsv PW VHF	Public Works / Water / Animal Control / Snow Plows	FMN	Public Works
458.55000	WNAH538	M	203.5 PL	Collnsv SS/Watr	Senior Shuttle / Water	FMN	Public Works
155.67000	KSA903	BM	CSQ	Collnsv EMA Old	Emergency Management: Old	FMN	Emergency Ops
154.35500	WPII568	F	186.2 PL	Coll Wx Sirens	Outdoor Warning Sirens - New	FMN	Emergency Ops

Dorsey (Village)

Dorsey Fire Protection District ^{Bunker Hill FB}

Division of Bunker Hill Fire Protection District, serves Dorsey and the surrounding area. Often provides Mutual Aid to agencies in southern Macoupin County.
159.435 Mobile Extenders (NFM) KAN769

Frequency	License	Type	Tone	Alpha Tag	Description	Mode	Tag
154.07000	KAN769	BM	516 DPL	Mac Frgrnd A	Fireground	FMN	Fire-Tac

Edwardsville (City) ^{WEB [ FB]}

Edwardsville Police Department Beat Map

911 PSAP for Edwardsville Police, Fire, EMS. Troy Police and SIUE Police.

Public Safety Building

Opened in 2018. $12 million facility in Edwardsville, housing both the Fire Department and the Police Department and 911 Dispatch. Each group will have their respective, dedicated areas, they will share the lobby, training room, fitness room, and emergency operations center. 52,000-square foot facility, vehicle bays include seven spaces for firetrucks and EMS vehicles. Info/Pics

Edwardsville Police Department ^{WEB FB Dispatch Photo}

2022 - New police car - getting a APX4500 mobile radio for $3224 (WirelessUSA)
Provides Free "Lockout" services for those that have locked keys in their personal vehicles

Former UHF Repeater could be patched to Starcom21 (for SIUE Police). (2008) Has a new radio system with multiple receive sites. Squelch data tails on mobiles.

458.850 KNHN539 B 203.5 PL (OLD) Police: Back-up FMN Deprecated (removed from DB 3/13/24)

~~453.850 KNHN539 M 203.5 PL (OLD) Police: Back-up FMN Deprecated (removed from DB 3/13/24)~~

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
453.97500	458.97500	KNHN539	RM	203.5 PL	Edw WarningSiren	Outdoor Warning Sirens: Data	FMN	Emergency Ops
154.17500	156.19500	WQBA905	RM	210.7 PL	EdwardsvilleFire	Fire: Dispatch (WPGM753)	FMN	Fire Dispatch
158.77500		KNAE820	BM	107.2 PL	Edw PublicWorks	Public Works [Expires 11/24]	FMN	Public Works

Edwardsville Fire Department ^{WEB FB}

Units: 1300s; Serves: Edwardsville city limits, SIUE, portions west of Edwardsville near the Gateway Commerce Center and portions east of Edwardsville near and east of I-55.
Fire (particularly EMS) may respond mutual aid to other districts, such as Marine, when needed

Edwardsville Public Works ^WEB

Primary functions include the maintenance of city streets, sidewalks, storm sewers, sanitary sewers, water mains; snow removal; solid waste collection; planning & zoning; building inspections; code enforcement; and the operation and maintenance of the City owned water and waste water treatment plants.(The water plant supplies Edwardsville, Southern Illinois University Edwardsville and the Northeast Central Water District.)
Parks and Recreation Department ^WEB

~~158.775 KNAE820 BM 107.2 PL Public Works FMN Public Works (OLD)~~
158.775 CSQ is also used to page Troy Fire from Glen Carbon Dispatch

~~464.8875 Repeater (w/469.8875) was licensed to IT Department, but never heard in use WQNT892 [Expired 5/21]~~

Fosterburg

Fosterburg Fire Protection District ^{WEB FB}

Units: 2300s; Serves: Foster Township and part of Wood River Township; 30 square miles and protect a population of about 5,000 persons.
Combination department and maintain full-time staffing at both stations. Career staff plus 20 volunteer.
BLS Non-Transport EMS/Rescue

Frequency	License	Type	Tone	Alpha Tag	Description	Mode	Tag
153.95000	KNEY877	BM	CSQ	Fosterburg FG 2	Fireground/Local [Ch 2]	FMN	Fire-Tac
160.05000	WQAK426	BM	CSQ	Fost WD Ops	Water District: Voice / Digital	FMN	Utilities
452.25000	WRMQ202	F		Fost WDD UHF	Fosterburg Water District (CSQ)	Telm	Data

Godfrey (Village) ^WEB

Incorporated in 1991. Police services have been provided by Madison County Sheriff since the early 1977s. Madison County provides 2 full-time officers 24/7. Godfrey is by far the largest municipality in the county geographically - the village maintains about 94 miles of road inside its limits but about 12 miles are still maintained by the county.

Assumed to be no longer in use, 151.025 is new WR Fire Repeater output

151.025 KTP829 BM 127.3 PL Godfrey Street [Expired 8/21] FMN Deprecated 8/9/24

EMS Provided by Alton Memorial Hospital Ambulance

Godfrey Fire Protection District ^{WEB FB}

Radio: Has access to QEM Fire 151.31R 88.5, Jersey County 155.805 179.9, Brighton ~~155.715 100.0~~
ALS Non-Transport EMS/Rescue
Largest FPD in the MetroEast (42 sq m) - Covers Godfrey Township, areas of Foster Township and a part in Jersey County.
Station 1 - 6011 Godfrey Road (Serves as district headquarters)
Station 2 - 1712 West Delmar (Board of Trustees - monthly meetings)

~~9/24 Village trustees are finalizing plans to lease Godfrey Fire Station #1 to Survival Flight 5, an air EMS service based in Jerseyville.~~

As of 3/25, only Alton Memorial Hospital Ambulance serves Godfrey

Currently consolidating two fire stations into one new facility on Godfrey Road, plans to be completely moved out of both current stations by the middle of January 2024.
"As far as the service it will provide to Godfrey, it's needed," McCormick said. "I think us, as a board, should be elated that we got an ambulance service wanting to come help a community like us."
The current Godfrey fire stations at 6011 Godfrey Road and 1712 West Delmar Ave. are scheduled to be closed following completion of the Godfrey firehouse now under construction on Godfrey Road. Village officials said they plan to use Station 2, on West Delmar, for the Godfrey Public Works Department. Plans originally called for Station 1 to be sold at auction.
The village plans to take ownership of Station 1 in January when the new consolidated firehouse is completed. Officials have said relocating Godfrey’s fire services into a single building, with all equipment housed in one central location, will allow for better emergency response and more efficient manpower allocation.

Survival Flight recently opened a new ground transportation base facility at 230 N Old Saint Louis Rd. in Wood River, Ill. Survival Flight’s local air transportation base facility is in Jerseyville, Ill.

Granite City (City) GOV MAPS

Facebook Scanner Groups: Original GC/PB Area granitecityscannerfeed3
Note: See MAPS above for clarification. There are parts of northern and eastern Granite City than intermingle with Mitchell Fire, Pontoon Beach boundaries

Granite City Police Department ^{WEB FB}

618-877-6111 - IWIN/MDCs used in squad cars
Police using Starcom21, see listings at the top of the page

Granite City Fire Department ^{WEB FB}

Units: 4400s; Serve 30,000 citizens who reside over 19 square miles. Responds to over 5100 calls a year, with 3 strategically located stations
EMS: 39 licensed paramedics and 15 engineers and captains that are State of Illinois registered First Responders
Station 1 Downtown 4A39 - 2300 Madison Ave
Station 2 (Pumper 2) - 2240 Rock Rd
Station 3 (has ambulance) - 223 Richmond

~~Former Frequencies~~

~~158.775 KKV545 M CSQ Police: Tactical [Ch 2] [Expired]~~

~~159.6 M CSQ Police: Mobile Extenders [No license]~~

Granite City Emergency Management

154.115 156.7 PL Outdoor Warning Siren Data (DTMF) (Monthly test on first Tuesday) (last heard 4/2/24)

Granite City Public Works/Parks ^WEB

Heard on 155.88 CSQ Snow Plows and "Street Base"

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
151.34000	153.77000	WNPG778	RM	123.0 PL	GrCty Fire/EMS	[OLD] Fire/EMS: Dispatch/Operations [Expired 5/24*]	FMN	Fire Dispatch
154.11500		WNDG340	BM	156.7 PL	GrCty Streets	Streets / Outdoor Warning Siren Data (DTMF)	FMN	Public Works
155.88000		WQFW581	BM	CSQ	GrCty LocalGovt	Public Works / Streets [Local Government]	FMN	Public Works
159.00750		WQGB665	M		GrCty PublicWrks	Public Works / Water Data (CSQ) [Expired 12/16]	FMN	Utilities
155.88000		WQFW581	BM	205 DPL	GrCty Street/A-C	Streets / Animal Control / Snow Plows	FMN	Public Works
154.47125		WQBF255	F		IA GrCty WDD A	Illinois-American Water Data (CSQ)	Telm	Data
159.69000		WRMB507	F		IA GrCty WDD B	Illinois-American Water Data (CSQ)	Telm	Data

Grantfork (Village)

Grantfork Fire Protection District ^FB

Units: 2900s; Serves: 36 square miles around Grantfork.
As of 5/1/24, EMS service will be by RuralMed (No longer using Highland EMS)

Hamel (Village)

Police using Starcom21, see listings at the top of the page

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
154.99500		KZT524	BM	CSQ	Hamel VillageOps	Village Ops [Expired]	FMN	Public Works
151.18250	159.17250	KW9095	RM	243 DPL	AlhHam Fire/EMS	Fire/EMS: Dispatch [Simulcast 154.43 167.9]	FMN	Fire Dispatch

Hamel Fire Protection District ^{WEB FB}

Units: 2700s; Serves: Most of Hamel Township, 50 square miles

Highland (City)

Highland Police Department ^{WEB FB}

151.0925 348 NAC - Encrypted TG 1 is units, TG 384 is RID 1/Dispatch (as of 1/24)
RIDs: 7000-Dispatch; units 7002, 7004, 7007, 7027, 7030, 7034, 7037) Linked to Madison County Sheriff talkgroup on SC21 (not encrypted)

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
154.35500		KSG687	BM		Highland FG	Fireground	FMN	Fire-Tac
453.27500	458.27500	KEG908	RM	203.5 PL	Highland Sirens	Outdoor Warning Siren Data	FMN	Emergency Ops
151.09250	153.79250	WQVQ384	RM	384 NAC	Highland Police	Police: Dispatch [TG 1/TG 384] (multicast on SC21 TG7015)	P25	Law Dispatch
155.10750	158.88750	WQVQ385	RM	385 NAC	Highland Fire	Fire/EMS: Response/Local (Paged on 155.5275) [TG 1]	P25	Fire Dispatch
159.20250	155.54250	KEG908	RM	396 NAC	Highland PubWrks	Public Works / Snow Plows [TG 1]	P25	Public Works
453.05000	458.05000	KEG908	RM		Highland Utility	Utilities	FMN	Utilities

Highland Fire / EMS ^{WEB FB}

Serves: City limits of Highland.
EMS for HP, Grantfork, Marine, St Jacob, St Rose
155.1075 385 NAC - ENC TG1 (RIDs: 7000-Dispatch, 7003, 7005, 7023, 7034, 7059 unit, 7060 unit, 7061 unit, 7062 EMS unit?)

3/24 - Highland EMS will no longer be serving St Jacob, Marine, Highland-Pierron and Grantfork Fire Protection Districts, St Rose FPD will be served by Highland through 2024, but may opt to join another provider. As if 5/1/24, the 5 districts will initially contract for 6 months with RuralMed EMS while the Fire Districts establish a new Ambulance District

A staffed ALS (Advanced Life Support) ambulance will be stationed at the Highland-Pierron firehouse on Iberg Road in Highland. This centralized location will minimize any changes in response times from what residents of each district currently receive. When that ambulance is dispatched, ambulances will begin moving into the area as available from other locations in the area, including Mitchell, Pontoon Beach, or Bond County. RuralMed EMS has an ALS quick response vehicle at their transfer base in Swansea that can provide all life saving services except transportation to a hospital as well as four trucks that can be dispatched as command centers for major catastrophe

The city of Highland has laid off EMS staff due to losing money in the past years, by poor Medicaid/Medicare reimbursements. After the cuts and district losses, Highland EMS estimates they will run about 3 EMS calls a day, although the firefighter's union says about 6.4 calls per day. EMS had 16 full time positions, with 3 unfilled. Another 5 will be laid off, leaving leaving 8 full time personnel. See Time Tribune Article Highland City Statement

Highland EMA ??

The City of Highland has 7 weather sirens located within the city. These sirens run silent tests daily to ensure they are functioning properly (no more 10am Tuesday morning wake up calls). During inclement weather, they are activated automatically according to criteria set by the National Weather Service. FB Post

Highland Public Works

159.2025 396 NAC - Talkgroup 1 (3/18) in the clear, not encrypted.
RIDs: 6039, 6047 (Edward 33), 7041 (City Office), 6023 (snow plow), 6059 (snow plow) last heard 1/5/25

Highland Light and Power"

Unknown radio/frequency usage

Highland-Pierron Fire Protection District ^FB

Serves areas east of Highland and Pierron (including Millersburg) (64 square miles) Korte Fire Station Project
See Highland above, as of May 2024, EMS service will be by RuralMed

~~Old Frequencies~~

~~453.05 KEG908 RM 203.5 PL Police: Dispatch - Old~~

~~453.25 WPSD749 RM Parks / Recreation (not 146.2 PL)~~

Holiday Shores (Unincorporated) ^WEB

Holiday Lake is a private lake located in Madison County and owned by Holishor Association

Electricity by Southwestern Electric Cooperative.
Water and Sewer by HS Sanitary District and Fosterburg Water District provides water to Lake James Subdivision
Gas by Ameren IL
Cable/Internet by Madison Communications
Trash Collection by Midland Waste

Holishor Security

Holiday Shores Public Safety 618-656-7294
Has volunteer Security Officers that check the lakes for boat stickers and keep on eye on the area, including vacation checks of homes.
Unknown VHF frequency used by Maintenance department

Holiday Shores Fire Protection District ^{WEB FB}

Units: 3300s; Serves 16 sq.m. north of Edwardsville (North to Prairietown and Bunker Hill FPDs, east to Hamel FPD, west to Meadowbrook FPD, and south to Edwardsville Fire District borders.
Operates 2 Pumpers, 2 Tankers and Brush/Rescue truck.
EMS provided by Alton Memorial Hospital EMS or Edwardsville Fire/EMS
BLS Non-Transport EMS/Rescue

Frequency	License	Type	Tone	Alpha Tag	Description	Mode	Tag
154.07000	KAN769	BM	516 DPL	Mac Frgrnd A	Fireground	FMN	Fire-Tac

Livingston (Village)

Frequency	License	Type	Tone	Alpha Tag	Description	Mode	Tag
154.99500	WQSA734	BM	CSQ	Livingston LG	Public Works / Police: Local / Olive FPD Fireground	FMN	Multi-Tac

Livingston-Williamson (Olive FPD) Fire ^FB

Units; 3600s; Serves the villages of Williamson and Livingston and some of the surrounding area. Former Olive (Township) Fire Protection District (Livingston)
EMS provided by Staunton Area Ambulance Service (SAAS) |Units
May use local frequency (154.995?) or Fireground Red on scene.

Marine (Village) ^WEB

Frequency	Input	License	Type	Tone	Alpha Tag	Description	Mode	Tag
155.77500		WRXD732	BM		Marine PubWrks	Public Works	FMN	Public Works
159.32250	154.43000	KZJ808	RM	167.9 PL	Marine Fire	Fire: Tone-Outs/Dispatch (Patch to County Fire)	FMN	Fire Dispatch

Marine Community Fire Protection District ^{WEB FB}

Fire may 155.055 IREACH for contact with ARCH/AireEvac
Units: 2800s; Serves: Marine Township and parts of the surrounding area.
35 dedicated and extensively trained men and women. Our volunteer firefighters and EMTs operate a fleet of 6 trucks and a rescue boat, including two pumpers, a rescue truck, a brush truck, a pumper/tanker, and a dedicated tanker. We respond to approximately 200 calls per year.
At 85 square miles, our district is one of the largest in Madison County, with boundaries of Fruit Road (to the North), Hickory Flat Road (to the South), Prairie Road (to the East), and the intersection of Pin Oak Road/State Route 143 in Edwardsville (to the West).
Contracted with Highland EMS to provide ALS medical care and transportation.

Meadowbrook (Village?)

Meadowbrook Fire and Rescue Protection District ^FB

Units: 3500s; Serves: 12 square miles
BLS Non-Transport EMS/Rescue; EMS provided by Alton-Memorial Hospital EMS

Moro (Unincorporated)

Police by Sheriff/Illinois State Police
EMS by Alton Memorial Ambulance
Fire by Bethalto Fire Department and/or Prairietown Fire

New Douglas (City)

New Douglas Fire Department ^{WEB FB}

Units: 3900s; Serves the surrounding area of New Douglas.
Paged on 154.43 by Madison County at Edwardsville tower, then repeats the page on a local tower
EMS by Staunton Area Ambulance Service (SAAS) |Units

Pierron

HPFD MAY BE LISTED TWICE
Highland-Pierron Fire Department ^{WEB FB}

Units: 4000s; HPFPD was organized in 1950 to serve the rural areas of Highland. HPFD currently serves 72 square miles, providing fire suppression, smoke/gas investigation, auto accident rescue, and First Responder medical care. Membership is made up of 40 volunteers living in the Highland and Pierron areas.
(Alternate) Serves areas east of Highland and Pierron (64 square miles: portions of Helvetia, Saline and Marine Townships in Madison County, portions of Burgess and Mills Townships in Bond County, and a small portion of St. Rose Township in Clinton County) Woodcrest Station
Station 1 - 241 Illinois Route 143, Pierron
Station 2 - 187 Woodcrest Dr, Highland

As of 5/1/24, EMS service will be by RuralMed (No longer using Highland EMS)

Some parts of the area, in Madison County, may have Pocahontas mailing addresses. The city itself is located in Bond County, however it is know that the Sheriff responds to the Deer Run/IL-143 area.

Prairietown (Village)

Prairie Fire Protection District ^{WEB FB}

Units: 3000s; Serves: Prairietown and the surrounding area.

Rosewood Heights (Village)

Rosewood Heights Fire Protection District ^FB

Units 1700s. Serves the village limits. EMS provided by Alton Memorial EMS.
BLS Non-Transport EMS/Rescue

St. Jacob WEB FB

Serves St. Jacob Village and Township. Mutual Aid with Highland, Highland-Pierron, Marine Fire Districts
As of 5/1/24, EMS service will be by RuralMed (No longer using Highland EMS)

Staunton (City)

Located in Macoupin County with part of the Fire/EMS district serving northeastern Madison County (Worden, Livingston, Williamson)

State Park Township

State Park Fire District (Caseyville/Collinsville)

Serves State Park Place / Township and rural areas near Caseyville and Collinsville, around I-255 (outside the city limits of Collinsville, to the south; mostly St Clair County)
2018 Fire - Uses talkgroup 8762 and others. (as of 5/18)

Trenton (City)

Located mostly in Clinton County

Williamson (Village)

Fire by Olive FPD (Livingston)
EMS by Alton Memorial Ambulance
Assumed to be patrolled by Madison County Sheriff

~~Williamson Police~~

~~Disbanded, now patrolled by Madison County Sheriff~~

~~FORMER - 154.0925R/158.8725 WPOX648 RM 131.8 PL Police: Tac/Phone Patch [Exp 10/04] [was still on air 4/10]~~

Worden (Village) ^WEB

Police using Starcom21, see listings at the top of the page

Worden Fire Protection District ^FB

Dispatched by Madison County on 154.43 167.9 PL
EMS by Staunton Area Ambulance Service (SAAS) Units
Units: 3400s; Serves: Worden and the surrounding rural route area.
EMS by Alhambra-Hamel Ambulance or Staunton

Return to DB page: Madison County (IL)
Return to Wiki page: Madison County (IL)

Madison County (IL) Municipalities and Districts

From The RadioReference Wiki

Contents

STARCOM21 Usage

Glen Carbon PSAP (GlenCom)

Glen Carbon (Village) WEB FB

Maryville (Village) WEB MAP

Saint Jacob (Village)

Troy (City) WEB FB

Pontoon Beach (Village)

Mitchell (Unincorporated)

Madison (City)

Venice (City)

Wood River Central Dispatch PSAP

Bethalto (Village) WEB FB

Cottage Hills (Unincorporated) WikiPedia Info

East Alton (Village) WEB FB

Hartford (Village)

Rosewood Heights (Village)

Roxana (Village) WEB

South Roxana (Village)

Wood River (City) WEB

Municipalities and Districts

Townships

Water, Sewer and Levee Districts

Alhambra (Village)

Alton (City) WEB

Brighton (Village)

Brooklyn (Village)

Collinsville (City) WEB

Dorsey (Village)

Edwardsville (City) WEB [ FB]

Fosterburg

Godfrey (Village) WEB

Granite City (City) GOV MAPS

Grantfork (Village)

Hamel (Village)

Highland (City)

Holiday Shores (Unincorporated) WEB

Livingston (Village)

Marine (Village) WEB

Meadowbrook (Village?)

Moro (Unincorporated)

New Douglas (City)

Pierron

Prairietown (Village)

Rosewood Heights (Village)

St. Jacob WEB FB

Staunton (City)

State Park Township

Trenton (City)

Williamson (Village)

Worden (Village) WEB

Glen Carbon (Village) ^{WEB FB}

Maryville (Village) ^{WEB MAP}

Troy (City) ^{WEB FB}

Bethalto (Village) ^{WEB FB}

Cottage Hills (Unincorporated) ^{WikiPedia Info}

East Alton (Village) ^{WEB FB}

Roxana (Village) ^WEB

Wood River (City) ^WEB

Alton (City) ^WEB

Collinsville (City) ^WEB

Edwardsville (City) ^{WEB [ FB]}

Godfrey (Village) ^WEB

Holiday Shores (Unincorporated) ^WEB

Marine (Village) ^WEB

Worden (Village) ^WEB
